QW-5117
TESTING: MODULE QW-51177.
MEASURING CURRENT CONSUMPTION7-1.
This model starts correct positioning of the second hand in the Hand Set mode immediately after AC.
When it is functioning, the value of consumption current would be a little higher as the internal circuit
operation would be different from the usual status.
Measure the current value at 5 seconds after AC is performed.
* Measure within one minute while light is blocked from the watch face.
* Supply voltage is 2.5V.
CHECKING THE MODEL7-2.
