Part IV
Setting Values and Send/ Receive Values
14 Setting Value Tables
14.1 Off/On Setting Value Table
Transmit Value Receive Value Parameter
00H 00H - 3FH Off
7FH 40H - 7FH On
14.2 –64 - 0 - +63 Setting Value Table
Transmit Value Receive Value Parameter
00H 00H -64
: : :
40H 40H 0
: : :
7FH 7FH +63
14.3 Pan Setting Value Table
Transmit Value Receive Value Parameter
00H 00H Left
: : :
40H 40H Center
: : :
7FH 7FH Right
14.4 Fine Tune Setting Value Table
Transmit Value Receive Value Parameter
(LSB, MSB) (LSB, MSB) - (LSB, MSB)
(43H, 00H) (00H, 00H) - (5FH, 00H) 415.5 Hz
(65H, 00H) (60H, 00H) - (7FH, 00H) 415.6 Hz
(07H, 01H) (00H, 01H) - (1FH, 01H) 415.7 Hz
(29H, 01H) (20H, 01H) - (3FH, 01H) 415.8 Hz
: : :
(40H, 3FH) (30H, 3FH) - (4FH, 3FH) 439.8 Hz
(60H, 3FH) (50H, 3FH) - (6FH, 3FH) 439.9 Hz
(00H, 40H) (70H, 3FH) - (1FH, 40H) 440.0 Hz
(20H, 40H) (20H, 40H) - (3FH, 40H) 440.1 Hz
(40H, 40H) (40H, 40H) - (5FH, 40H) 440.2 Hz
: : :
(54H, 7EH) (50H, 7EH) - (6FH, 7EH) 465.6 Hz
(73H, 7EH) (70H, 7EH) - (0FH, 7FH) 465.7 Hz
(11H, 7FH) (10H, 7FH) - (2FH, 7FH) 465.8 Hz
(30H, 7FH) (30H, 7FH) - (7FH, 7FH) 465.9 Hz
