CONTENTS
TE-7000S/8000F/8500F PAGE
1. SPECIFICATIONS........................................................................................ 1
2. CONNECTOR LOCATIONS ........................................................................ 4
3. MACHINE INITIALIZATION ......................................................................... 5
4. DISASSEMBLY............................................................................................ 9
5. CIRCUIT EXPLANATION .......................................................................... 17
6. OPTION INSTALLATION........................................................................... 34
7. IN LINE ....................................................................................................... 36
8. ON LINE ..................................................................................................... 39
9. DIAGNOSTIC OPERATION....................................................................... 41
10. ERROR CODE LIST................................................................................... 65
11. IC DATA ..................................................................................................... 70
12. PCB LAYOUT ............................................................................................ 76
13. CIRCUIT DIAGRAMS................................................................................. 80
14. PARTS LIST............................................................................................. 103
To prevent malfunctions caused by the weak batteries, charge the memory
protection batteries for over 12-hours before installation or after a long-time
vacation (over 30 days).
• Before installation, initialize the terminal and leave it turn on over 12-hours.
• After a long-time vacation, initialize the terminal and restore the program data if
the terminal is in malfunction, and leave it turn on over 12-hours.
• Over 48-hours charging makes the batteries fully charged.
