■ HOST INTERFACE
Pin Names Type Pin# Cell RESET# Description
State
This pin has multiple functions.
• For SH-3/SH-4 mode, this pin inputs system address bit 0 (A0).
• For MC68K #1, this pin inputs the lower data strobe (LDS#).
AB0 I 70 CS Input • For MC68K #2, this pin inputs system address bit 0 (A0).
• For Generic #1, this pin inputs system address bit 0 (A0).
• For Generic #2, this pin inputs system address bit 0 (A0).
45, 53, 54,
55, 56, 57,
AB[16:1] I 58, 59, 62, C Input These pins input the system address bits 16 through 1 (A[16:1]).
63, 64, 65,
66, 67, 68,
69
These pins have multiple functions.
• For SH-3/SH-4 mode, these pins are connected to [D15:0].
3, 4, 5, 6, 7, • For MC68K #1, these pins are connected to D[15:0].
DB[15:0] IO 8, 9, 11, 12, C/TS2 Hi-Z • For MC68K #2, these pins are connected to D[31:16] for a
13, 14, 15, 32-bit device (e.g. MC68030) or D[15:0] for a 16-bit device
16, 17, 18, (e.g. MC68340).
19 • For Generic #1, these pins are connected to D[15:0].
• For Generic #2, these pins are connected to D[15:0].
This pin has multiple functions.
• For SH-3/SH-4 mode, this pin inputs the write enable signal for
the lower data byte (WE0#).
• For MC68K #1, this pin must be tied to IO V DD
WE0# I 77 CS Input • For MC68K #2, this pin inputs the bus size bit 0 (SIZ0).
• For Generic #1, this pin inputs the write enable signal for the
lower data byte (WE0#).
• For Generic #2, this pin inputs the write enable signal (WE#).
5-10-3. Pin Function
■ KEY
I = Input
O = Output
IO = Bi-Directional (Input/Output)
P = Power pin
C = CMOS level input
CS = CMOS level Schmitt input
COx = CMOS output driver, x denotes driver type (see I OL /I OH in Table 6-4: “Output Specifications,” on
page 25)
TSx = Tri-state CMOS output driver, x denotes driver type (see I OL /I OH in Table 6-4: “Output Specifications,”
on page 25)
CNx = CMOS low-noise output driver, x denotes driver type (see I OL /I OH in Table 6-4: “Output
Specifications,” on page 25)
TEST = CMOS level test input with pull down resistor
