— 2 —
Scale cable
SCL-CB-10
Cut the masking cover for In-line
connector
Check whether those capacitors are lying.
In-line cables
Locking supporters
Cable fixing plate
Cable supporter
Cut the masking
part if necessary.
I/O-PB-11
Cut the masking cover for ON-line
connector.
Cut the masking cover for scale.
Scale cable
