Casio IT-G500 User Manual

– 27 –
IT-G500

Y
Cradle I/F (USB HOST)
No. Operation Test Details
1
Select [2].Cradle I/F (USB Host). (MENU-6)
Set a USB memory and then IT-G500 to the
cradle.
Press the “ENT” key.
A test fi le (approx. 64 KB) is written, read,
and compared, for the USB memory.
If OK:
“OK” appears.
If any problem:
An error indication is displayed.
Press the “ENT” key to return to the menu
screen.

Y
micro USB I/F(USB HOST)
No. Operation Test Details
1
Select [4].micro USB I/F(USB HOST). (MENU-6)
Connect IT-G500 and a USB memory with the
USB cable (for host).
Press the “ENT” key.
A test fi le (approx. 64 KB) is written to, read,
and compared, for the USB memory.
If OK:
“OK” appears.
If any problem:
An error indication is displayed.
Press the “ENT” key to return to the menu
screen.

Casio IT-G500 Specifications

General

Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	CMOS
Scanner type	2D
Tilt reading angle	0 - 25 °
Optical sensor resolution	0.25 pixels
Linear (1D) barcodes supported	Codabar, Code 128, Code 32, Code 39, Code 93, EAN-13, EAN-8, MSI
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, MaxiCode, Micro QR Code, MicroPDF417, QR Code
Battery voltage	3.7 V
Power source type	Battery
Battery technology	Lithium
USB version	2.0
Standard interfaces	USB, Bluetooth, Wireless LAN
Connectivity technology	Wireless
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
RAM capacity	512 MB
Keys quantity	22 keys
Product color	Black
LED indicators	Charging, Status
Internal memory	4000 MB
Built-in display	Yes
Housing material	-
Display resolution	480 x 800 pixels
Display technology	LCD/TFT
Processor frequency	1.5 MHz
Protection features	Dust resistant, Water resistant
International Protection (IP) code	IP67

Weight and Dimensions

Depth	22 mm
Width	74 mm
Height	175 mm
Weight	270 g
