– 38 –
IT-G500
Y
W-LAN
<Required equipment>
Connect equipment as follow.
W-LAN access point
(Recommendation: Cisco 1231G)
Test Object
Wireless
Transmission
<Testing procedure>
No. Operation Test Details
1
Select “Start” – “Settings” – “Connections” –
“WLAN Settings” in that order.
In the WLAN Setting screen, select “WLAN” tab.
Check “On” of the “Adapter power”, and tap
“OK”.
2
Select “Basic”, “WLAN” or “Detail Settings” tab.
Then, input “SSID”, “IP address”, etc. of the
target access point.
3
Select “Start” – “NetSearch” in that order.
Tap “Tools” and then select “Ping” or “Signal”.
Carry out wireless test using “Ping” and
“Signal” functions.
Check if the test results are acceptable
comparing with a good IT-G500.
To Next Page
