– 49 –
IT-G500
Disassembling the LOWER-CASE-UNIT
PACKING/EXT
2D model
FILTER/2D
Non-NFC model
BLIND/RFID
Laser model
FILTER/LASER
CAMERA model
FILTER/CAMERA
Non-camera model
BLIND/CAMERA
+
D-TAPE/CAMERA BLIND
CAP/microSD
Screw (S3)
CAP/AUDIO
Screw (S3)
[ Note on reassembling ]
Be sure that no dust is attached to the blue-
colored part shown below.
Disassembling the LOWER-CASE-UNIT


Casio IT-G500 Specifications

General

Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	CMOS
Scanner type	2D
Tilt reading angle	0 - 25 °
Optical sensor resolution	0.25 pixels
Linear (1D) barcodes supported	Codabar, Code 128, Code 32, Code 39, Code 93, EAN-13, EAN-8, MSI
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, MaxiCode, Micro QR Code, MicroPDF417, QR Code
Battery voltage	3.7 V
Power source type	Battery
Battery technology	Lithium
USB version	2.0
Standard interfaces	USB, Bluetooth, Wireless LAN
Connectivity technology	Wireless
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
RAM capacity	512 MB
Keys quantity	22 keys
Product color	Black
LED indicators	Charging, Status
Internal memory	4000 MB
Built-in display	Yes
Housing material	-
Display resolution	480 x 800 pixels
Display technology	LCD/TFT
Processor frequency	1.5 MHz
Protection features	Dust resistant, Water resistant
International Protection (IP) code	IP67

Weight and Dimensions

Depth	22 mm
Width	74 mm
Height	175 mm
Weight	270 g
