Casio IT-G500

– 63 –
IT-G500
(8) Remove the coaxial cable (WLAN-UNIT/5G) and EXT-UNIT.
1
2
EXT-UNIT
45 ± 10°
Coaxial cable
[ Note on reassembling ]
Run the coaxial cable under the case and
connect it in place while paying attention to its
orientation.
(9) Undo 4 screws.
4 screws (S9)
