— 32 —
37
54
51
41
48
46
44
45
47
43
49
50
50
42
60
36
38
39
40
5. UPPER CASE BLOCK
Item Code No. Parts Name Specification Version Q R
UPPER CASE BLOCK
36 6246 1740 Upper case E266 E110368-1 1 X
37 6246 1790 Display plate E266B (PCR-260) E110370-2 1 C
37 6246 1800 Display plate E267B (PCR-255) E110370-3 1 C
38 6246 2740 FPC E266 E311855-1 1 B
39 6246 2750 Common sheet E266 E311856-1 1 B
40 6246 2760 Spacer E266 E311857-1 1 B
41 6246 2030 Mode key plate E266BC (PCR-260) E412138-11 1 C
41 6246 2040 Mode key plate E266BC (PCR-255) E412138-12 1 C
42 1090 5329 Printer unit M-42V-001-060MA 1 A
43 6322 4499 Battery spring A-G55 A42606-1 1 X
44 6000 6091 Battery spring G67 A43656-1 1 X
45 6001 0862 Battery spring B-1 P408-1 1 X
46 6001 0871 Battery spring B-2 P409-1 1 X
47 6221 2284 Connector sub ass'y (Black) E411265*1 1 X
48 6221 2292 Lead wire sub ass'y (Red) E411266*1 1 X
49 6192 4970 Mode switch ass'y E311944*1 1 B
50 (+) Scew with washer 3x10 ZMC-3 6 X
