– 17 –
SE-S400/SE-S800/PCR-T500/PCR-T520/SE-C450
SE-S3000/SE-S900/PCR-T2300/PCR-T2400/SE-C3500
J-3. Disengage four hooks and then remove the MASK/R-DISPLAY.
CASE/R-DISPLAY
PCB ASSY/E291-E2-2
MASK/R-DISPLAY
BOARD/R-DISPLAY
W-TAPE/110X4.5
W-TAPE/45X9.5
NOTES ON ASSEMBLY
Be sure that the LCD surfaces are clean.
