EN-55
Reference
• Specifications and designs are subject to change without notice.
Inputs/Outputs
PHONES jacks Stereo mini jacks (3.5mm) × 2
Power 12V DC
LINE OUT R, L/MONO jacks Standard jacks (6.3mm) × 2
Output impedance: 600Ω
Output voltage: 1.3V (RMS) MAX
USB port Type A, Type B
DAMPER PEDAL jack Standard jack (6.3mm)
PEDAL UNIT jack Proprietary jack
Acoustics
Amp output 8W + 8W
Speakers 16cm × 8cm (oval) × 2
Power Supply 2-way
Batteries 6 AA-size alkaline batteries
Continuous Operation: Approximately 4 hours
Playback of built-in demo tunes on alkaline batteries
Actual continuous operation time may be shorter due to battery type and
performance type.
AC Adaptor AD-A12150LW
Auto Power Off Approximately four hours (under AC adaptor power) or six minutes (under battery
power) after last operation; Can be disabled.
Power Consumption 12V=10W
Dimensions 132.2 (W) × 23.2 (D) × 10.2 (H) cm (52 1/16 × 9 1/8 × 4 inch)
Weight Approximately 11.2kg (24.7 lbs) (without batteries)
