EN-78
Reference
*1 Names of parameters included in the 58 “FREEZE” directory (“Freeze Function”, page EN-42). If you do not want settings made
with the knobs to be replaced when a registration function setup is recalled, select “On” as the settings of the FUNCTION
parameters in this column (Knob: 60, Effect: 64, Tone: 70, Accompaniment: 69).
For information about FUNCTION parameters, see “Configuring Function Settings (FUNCTION Mode)” (page EN-53).
*2 The parameters affected by this knob set are two parameters that are automatically selected as being the most applicable to the
currently selected DSP (“Using a DSP”, page EN-23). DSP Parameter 1 and DSP Parameter 2 are fixed according to the
selected DSP. For example, when preset DSP “15. Auto Pan” is selected, DSP Parameter 1 is LFO Rate, and DSP Parameter
2 is Manual.
Knob Set List
No.
Knob Set
(displayed)
(K1) knob (K2) knob
Applicable Part
Parameter Freeze*
1
Parameter Freeze*
1
1 Filter Cut Off Frequency Knob Resonance Knob Upper1
2 Brilliance/Rev Brilliance Effect Reverb Send Knob Upper1
3 Up1 Cho/Rev Chorus Send Effect Reverb Send Sound Mode Upper1
4 Amp Envelope Attack Time Knob Release Time Knob Upper1
5 Vibrato Vibrato Rate Knob Vibrato Depth Knob Upper1
6 Delay Vibrato Delay Vibrato Time Knob Vibrato Depth Knob Upper1
7 Porta./Mod. Portamento Time Knob Modulation Depth Knob Upper1
8 Layer Modify Layer Volume Balance Tone Upper2 Fine Tune Knob Upper1, Upper2
9 Layer Panning Upper1 Pan Knob Upper2 Pan Knob Upper1, Upper2
10 Lower Modify Lower Volume Tone Lower Pan Knob Lower
11 Kbd Cho/Rev Keyboard Chorus Send Effect Keyboard Reverb Send Sound Mode Upper1, Upper2,
Lower
12 Kbd/Acmp Vol. Keyboard Volume Tone Accompaniment Volume Accompaniment Upper1, Upper2,
Lower
13 Kbd/Song Vol. Keyboard Volume Tone Song Volume – Upper1, Upper2,
Lower
14 DSP Param.*
2
DSP Parameter 1 Tone DSP Parameter 2 Tone Upper1
To Next Page
