Casio PX-110 Service Manual

N Item Parts Code Parts Name Specification Q
Price
Code
R Remarks
Main PCB
N 1 10208341 PCB ASSY-MAIN TK-RJM506205*001 1 DK A
N
BT1 10209154 BATTERY CR2032T6X 1 AF C
D2
10133383 DIODE 02DZ2.7-Z(TPH3) 1 AA X
N
D3
10098748 DIODE 02DZ5.6-Y(TPH3) 1 AA X
D1
23902576 DIODE RB501V-40TE-17 1 AB X
F8,F9
10122975 FILTER EZASSB516BJ 2 AA C
F1,F5,F6,F7,F10,F11
10122976 FILTER EZASTB63ABJ 6 AA C
F3
30251862 FILTER NFM51R00P206 1 AC C
N
IC8,IC13
10211950 IC NJM2068M-D(TE1) 2 AC X
IC5
10175415 IC R1151N001C-TR-FB 1 AE X
IC12
10197798 IC TC74LCX138FT(EL.K) 1 AI X
IC16
10197802 IC TC74VHCT08AFT(EL.K 1 AE X
IC9
10197553 IC TC7S04FU(TE85L.F) 1 AA X
IC10
10137770 IC TC7S08FU(TE85L.F) 1 AA X
IC6
10197554 IC TC7SZ126FU(TE85L.F 1 AE X
IC15
10195928 IC UPD63200GS-E1-A 1 AX X
N
IC3,IC4
10198126 MEMORY CY62128DV30LL70ZAX 2 AU X
N
IC1
10209466 MEMORY MR27V6402G19PTN03D 1 BH X
Q1
22592764 TRANSISTOR 2SB1188T100Q 1 AB C
Q4
22530715 TRANSISTOR 2SD1664T100Q 1 AA C
N
Q2
10202670 TRANSISTOR KTA2014-GR-RTK/P 1 AA C
N
Q3
10207675 TRANSISTOR KTC4075-GR-RTK/P 1 AA C
D7
23903101 DIODE 02DZ6.8-Y(TPH3.F) 1 AA X
Sub PCB PS1
N 2 10208342 PCB ASSY/PSA1 TK-RJM506208*001 1 CL C
N
D201,206
10209003 DIODE 1N5822-F100 2 AB X
N
D213
10201501 PHOTO COUPLER PC900V0NSZXF 1 AG X
N
E202
10211947 RELAY G5PA-28DC5V(PF) 1 AN X
N
IC201
10203081 IC LA4636-E 1 AV X
N
IC202
10201503 IC PQ1CG21H2FZH 1 AO X
N
IC203
10209159 IC SN74HCT04AN 1 AC X
N
CN211
10212700 HARNESS DS-14P-15-M404 1 AH X
N
CN209
10212718 HARNESS SAN-5P-77-M404 1 AE X
N
CN204
10212702 HARNESS SCN-3P-69-M404 1 AC X
N
CN207
10212701 HARNESS SCN-4P-63-M404 1 AD X
D208
10079929 DIODE SRT14TA 1 AA X
D202,204,205,212
10079928 DIODE 1SS133TA 4
AA X
D203
10132124 DIODE DZ8.2BSBTA 1 AA X
Q202
10025042 TRANSISTOR 2SD1468STPR 1 AA X
N
Q205
10209017 TRANSISTOR KTA1267-GR-AT/P 1 AA X
N
Q201,203,204,206,208
10206673 TRANSISTOR KTC3199-GR-AT/P 5 AA
X
Jack PCB
N 3 10208343 PCB ASSY/JKB1 TK-RJM506210*001 1 AU C
N
J505,506 10206815 JACK JY-6314*01-030 2 AA X
Notes: N- New parts
Q-Quantity used per unit
- 23 -

Casio PX-110 Specifications

General

Polyphony	32 notes
Speakers	2 x 12cm
Amplifier Output	8W + 8W
Digital Effects	Reverb, Chorus
Touch Sensitivity	3 levels, Off
Metronome	Yes
Transpose	Yes
Tuning	Yes
Pedals	1 (Sustain)
Connectors	Headphone, Pedal
Power Supply	AC adapter (AD-12)
Included Accessories	AC adapter
Keyboard Type	88-key weighted hammer action
