Casio PX-110 Service Manual

N Item Parts Code Parts Name Specification Q
Price
Code
R Remarks
Case unit
N 25 10208334 COVER/SPEAKER L TK-RJM506070*001 1 AW C
N 26 10208329 COVER/SPEAKER R TK-RJM506069*001 1 AW C
N 27 10214565 SPEAKER C0612J52 2 AU B
N 28 10212713 HARNESS EH-2P-46-M404 1 AA C
N 29 10212715 HARNESS EH-2P-78-M404 1 AB C
N 30 10211772 KNOB/ROTARY RJM502503-011V01 1 AA C
N 30 10211866 KNOB/ROTARY RJM502503-013V02 1 AA C
PX-110DK
N 31 10203519 BUTTON/TACT/A RJM505580-002V01 1 AB C
N 31 10203525 BUTTON/TACT/A RJM505580-008V01 1 AA C
PX-110DK
N 32 10203520 BUTTON/TACT/A RJM505580-003V01 2 AC C
N 32 10203526 BUTTON/TACT/A RJM505580-009V01 2 AA C
PX-110DK
N 33 10203528 BUTTON/TACT/B RJM505686-001V01 11 AA C
N 33 10203534 BUTTON/TACT/B RJM505686-007V01 11 AA C
PX-110DK
34 69245260 BUTTON/PW M340318-1 1 AA C
N 35 10208340 PCB ASSY/JKA1 TK-RJM506218*001 1 BE X
CN409 35016944 CONNECTOR B5B-PH-K-S 1 AA X
CN410 10081222 DIN JACK HDC-052S-02 1 AF X
N
J401,402 10208979 JACK JY-3567*01-070 2 AC X
N
J403 10208247 DC JACK DJ-0702B*019 1 AA X
SW401 69324103 SWITCH SDKLA11000 1 AK X
N 36 10203501 CASE/SIDE IL RJM505581-001V01 1 AO C
N 37 10203504 CASE/SIDE IR RJM505582-001V01 1 AN C
N 38 10203507 CASE/SIDE L RJM505583-001V01 1 AQ C
N 39 10203510 CASE/SIDE R RJM505584-001V01 1 AS C
40 10129909 NUT/SUPPORT RJM503163-001V01 4 AC X
41 34121827 SWITCH SDDLD1-A2-D 1 AM C
42 10176916 HARNESS EH-2P-8-M419 1 AA C
43 10203785 SCREW S-TRMA-6X30B3 4 AA C
44 10311215 FELT/HAM U RJM509043-001V01 1 BI X
REFURBISH
N R-1 10208313 PANEL ASSY TK-RJM505972*001 1 CF C
N R-1 10208319 PANEL ASSY TK-RJM505972*002 1 CF C
PX-110DK
N R-2 10208339 CASE ASSY/LOWER TK-RJM505967*001 1 BX C
45 10258844 FELT/HAM L RJM507395-001V02 1 BB X
ACCESSORY
- 10133504 PEDAL ASSY TK-RJM503195*001 1 BN C
- 10128659 AC ADAPTOR AD-12UL-TC2(D) 1 CE C 120V
- 10168517 AC ADAPTOR AD-12FL-TC3(D) 1 CC C 230V
N - 10203517 STAND/MUSIC RJM503703-002V01 1 AY C
- 10100792 CORD SET INQ.1258(1) 1 AP C Korea
- 10045706 CORD SET EC2NC-M001A 1 AM C Euro type
- 10045707 CORD SET BC2NC-M001A 1 BD C UK type
N - 10209207 COVER/DUST RJM506261-001V01 1 BD X
OPTIONAL STAND(CS-65P)
N - 1022 7905 SCREW SET TK-RJM506109*001 1 BH C
1022 7906 SCREW SET TK-RJM506109*002 1 BI C PX-110DK
Notes: N- New parts
Q-Quantity used per unit
- 25 -

Casio PX-110 Specifications

General

Polyphony	32 notes
Speakers	2 x 12cm
Amplifier Output	8W + 8W
Digital Effects	Reverb, Chorus
Touch Sensitivity	3 levels, Off
Metronome	Yes
Transpose	Yes
Tuning	Yes
Pedals	1 (Sustain)
Connectors	Headphone, Pedal
Power Supply	AC adapter (AD-12)
Included Accessories	AC adapter
Keyboard Type	88-key weighted hammer action
