Casio PX-410R Service Manual

— 23 —
PX400R PX575R
Console PCB
N 5 10249879 PCB ASSY/CNA TK-RJM507277*001 1 1 C
CNA1~
CNA8
IC601 10159709 LSI UPD65881GK-1019ETA 1 1 X
X601 10093909 RESONATOR CSBLA1M00J58-B0 1 1 X
N D604 10251890 LED LT2P71-81-M1 1 1 X
N
D606,607,
608,609
10131987 LED T-3216SRD-PRV 4 4 X
D601-603,
605
10171338 LED LT2P71-81-M1-S06 4 4 X
VR601 10122556 VARIABLE R RK09K12C0D1A 1 1 X
VR602 10122622 VARIABLE R RK09D1130C49 1 1 X
N
SW601-608,
618,619,
632-673
10245364 TACT SWITCH THVV501BAA 40 40 X
N SW609-617 10247739 SWITCH SKRGAKD010 9 9 X
D610-621 10079928 LED 1SS133TA 12 12
Key board assy
6 10133488 PCB ASSY/KYA(KYA1,KYA3) TK-RJM503365*001 1 1 BI C 1set:2pcs.
D801-854,
923-976
10079928 DIODE 1SS133TA 108 108 AA X
7 10133482 PCB ASSY/KYB TK-RJM503366*001 1 1 BC C
D855-922 10079928 DIODE 1SS133TA 68 68 AA X
CN803 35017294 CONNECTOR 30FMZ-ST 1 1 AF X
8 10133656 RUBBER/CONTACT RJM502920-001V01 7 7 AK B
9 10133635 RUBBER/CONTACT RJM502921-001V01 1 1 AG B
10 10135317 BLACK KEY RJM502797-001V01 36 36 AC C
11 10135426 WHITE KEY/CEGB RJM502862-001V01 7 7 AT C
12 10135427 WHITE KEY/DFA RJM502863-001V01 7 7 AQ C
13 10135428 WHITE KEY/B RJM502794-001V01 1 1 AG C
14 10135429 WHITE KEY/SA RJM502795-001V01 1 1 AJ C
15 10135430 WHITE KEY/SC RJM502796-001V01 1 1 AJ C
16 10135435 HAMMER ASSY/W1 TK-RJM503155*001 13 13 AL C
17 10135436 HAMMER ASSY/W2 TK-RJM503216*001 13 13 AL C
18 10135437 HAMMER ASSY/W3 TK-RJM503217*001 13 13 AL C
19 10135438 HAMMER ASSY/W4 TK-RJM503218*001 13 13 AL C
20 10135439 HAMMER ASSY/B1 TK-RJM503219*001 9 9 AK C
21 10135440 HAMMER ASSY/B2 TK-RJM503220*001 9 9 AK C
22 10135442 HAMMER ASSY/B3 TK-RJM503221*001 9 9 AK C
23 10135443 HAMMER ASSY/B4 TK-RJM503222*001 9 9 AK C
24 10171298 NUT RJM504318-001V01 6 6 X
25 10171845 KEY UNIT TK-RJM504178*002 1 1 B
26 10027792 CABLE N30385B1B05-UL2896 1 1 X
27 10164305 CHASSIS ASSY TK-RJM504180*001 1 1 C
Case unit
N 28 10249873 COVER ASSY/SPEAKER/LEFT TK-RJM507155*001 1 1 C
N 29 10249874 COVER ASSY/SPEAKER/RIGHT TK-RJM507156*001 1 1 C
N 30 10229142 SPEAKER C05JH61 2 2 B Small
N 31 10229143 SPEAKER C0816J06 2 2 B Big
32 10175762 PACKING RJM504765-001V01 4 4 X
33 10175472 BOX ASSY/SPEAKER/LEFT TK-RJM504741*001 1 1 X
34 10175475 BOX ASSY/SPEAKER/RIGHT TK-RJM504742*001 1 1 X
N 35 10238919 PLATE/DISPLAY RJM506639-001V01 1 1 C
36 10216354 KNOB/ROTARY RJM502503-015V02 1 1 C
N 37 10248733 KNOB/ROTARY RJM502394-010V02 1 1 C
N 38 10247720 RUBBER/KEY/A RJM506640-001V01 2 2 C
N 39 10247721 RUBBER/KEY/B RJM506641-001V01 1 1 C
Notes: N- New parts R -A: Essential
Q- Quantity used per unit B: Stock recommended
R- Rank C: Others
X: No stock recommended
QTY
Price
Code
N Item
Parts
code
Parts Name Specification R Remarks
