PIN NO PIN NAME I / O DESCRIPTION
68 A13 OUT Address bus (A13)
69 VssQ - I/O Power supply (0V)
70 A14 OUT Address bus (A14)
71 VccQ - I/O Power supply (3.3V)
72 A15 OUT Address bus (A15)
73 A16 OUT Address bus (A16)
74 A17 OUT Address bus (A17)
75 A18 OUT Address bus (A18)
76 A19 OUT Address bus (A19)
77 A20 OUT Address bus (A20)
78 A21 OUT Address bus (A21)
79 Vss - VSS
80 A22 OUT Address bus (A22)
81 Vcc - VCC
82 A23 OUT Address bus (A23)
83 VssQ - VSS
84 A24 OUT Address bus (A24)
85 VccQ - I/O Power supply (3.3V)
86 A25 OUT Address bus (A25)
87 BS/PTK[4] (_1:) OUT/I/O Not used
88 RD OUT Read strobe
89 WE0/DQMLL OUT D7-D0 select signal / DQM (EDO)
90 WE1/DQMLU/WE OUT DQM (EDO) / Write strobe (PCMCIA)
91 WE2/DQMUL/ICORD / PTK [6] OUT/OUT/OUT/I/O DQM (SDRAM) / PCMCIA I/O Read signal
92 WE3/DQMUU/ICOWR / PTK [7] OUT/OUT/OUT/I/O DQM (EDO) / PCMCIA I/O Write signal
93 RD/WD (_1:) OUT Read / Wrie signal
94 AUDSYNC/PTE[7] OUT/I/O COM1 DTR
95 VssQ - I/O Power supply (0V)
96 CS0/MCS/PTE[7] OUT Chip select for FROM
97 VccQ - I/O Power supply (3.3V)
98 CS2/PTK[0] OUT/I/O Not used
99 CS3/PTK[1] OUT/I/O Not used
100 CS4/PTK[2] OUT/I/O Not used
101 CS5/CE1A/PTA[3] OUT/OUT/I/O CE1 (Area5 PCMCA)
102 CS6/CE1B OUT/OUT/I/O CE1 (Area6 PCMCA)
103 CE2A/PET[4] OUT/I/O CE2 (Area5 PCMCA)
104 CE2B/PET[5] OUT/I/O CE2 (Area6 PCMCA)
105 CKE/PTK[5] OUT/I/O Not used
106 RAS3L/PTJ[0] OUT/I/O RAS for RAM (RAM1,2)
107 RAS2L/PTJ[1] OUT/I/O Not used
108 CASLL/CASL/PTJ[2] OUT/I/O CAS for RAM (RAM1,3)
109 VssQ - I/O Power supply (0V)
110 CASLH/CASU/PTJ[3] OUT/I/O CAS for RAM (RAM1,3)
111 VccQ - I/O Power supply (3.3V)
112 CASHL/PTJ[4] OUT/I/O CAS for RAM (RAM2)
113 CASHH/PTJ[5] OUT/I/O CAS for RAM (RAM2)
114 DACK0/PTD[5] OUT/I/O Not used
115 DACK/PTD[7] OUT/I/O Not used
116 CAS2L/PTE[6] OUT/I/O Not used
117 CAS2H/PTE[3] OUT/I/O Not used
118 RAS3U/PTE[2] OUT/I/O RAS for RAM (RAM3)
119 RAS3U/PTE[1] OUT/I/O Not used
120 TDO/PTE[0] OUT/I/O DATA OUTPUT (H-UDI)
121 BACK OUT Not used
122 BREQ IN Not used
123 WAIT IN WAIT signal (PCMCIA)
124 RESETM IN RESET signal
125 ADTRG/PTH[5] IN Not used
126 I/OIS16/PTG[7] IN/I/O IOIS16 (PCMCIA)
127 ASEMDO/PTG[6] IN ASE mode (H-UDI)
128 ASEBRKAK/PTG[5] OUT/I/O ASE break (H-UDI)
129 PTG[4] IN/OUT Not used
130 AUDATA[3]/PTG[3] I/O Not used
131 AUDATA[2]/PTG[2] I/O Not used
132 Vss - VSS
133 AUDATA[1]/PTG[1] I/O Not used
134 Vcc - VCC (1.9V)
135 AUDATA[0]/PTG[0] I/O Not used
136 TRST/PTF[7]/PINT[5] IN RESET (H-UDI)
137 TMS/PTF[6]/PINT[14] IN MODE SELECT (H-UDI)
138 TDI/PTF[5]/PINT[13] IN DATA INPUT (H-UDI)
139 TCK/PTF[4]/PINT[12] IN CLOCK (H-UDI)
