Casio QT-2100 Service Manual

N Item Code No. Parts Name Specification Price Rank
Code
1. MAIN PCB BLOCK
N
1
10073421 PCB ASSY/E590-1 E240831*1 1 EJ A
N
1
10073422 PCB ASSY/E590-1 E240831*2 1 EJ A
N IC7 10074040 LSI HD6417709AF133B 1 1 CT A
N IC11 10075914 LSI UPD784215AGC1698EU 1 1 BN A
N IC15 10073986 LSI UPD65945GJ-P16-JEU 1 1 BU A
N IC9 10083006 LSI MBM29DL324BE90TN-C 1 1 CG A
N IC8,12 10074499 LSI M51V18165DSL-6TKFB 2 2 BT A
N IC1 10074500 LSI LC35256FT-70U-TLM 1 1 BA A
N IC4 10074501 LSI S1D13503F00A100 1 1 CD A
IC14 10006024 LSI COM20019ILJP 1 1 CF A
N IC26 10073989 IC/MOS TC74HC4050AFT 1 1 AF A
N IC20,29 10073990 IC/MOS HD74LV00ATELL 2 2 AB A
N IC19,22 10073991 IC/MOS HD74LV07ATELL 2 2 AD A
N IC28 10073992 IC/MOS HD74LV10ATELL 1 1 AB A
N IC18 10073993 IC/MOS HD74LV1G00ACME 1 1 AA A
N IC24 10073994 IC/MOS HD74LV74ATELL 1 1 AB A
N IC27 10073995 IC/MOS HD74LV86ATELL 1 1 AB A
N IC23,25 10073996 IC/MOS HD74LVC08TELL 2 2 AC A
N IC21 10073998 IC/MOS HD74LVC138TELL 1 1 AE A
IC3,5 10005674 IC/MOS HD74LVC244ATELL 2 2 AF A
IC2,6 10005676 IC/MOS HD74LVC245ATELL 2 2 AF A
N IC45,46 10074000 IC/MOS HD74HCT1G08CME 2 2 AA A
N IC17 10074001 IC/MOS XC6201P192MR 1 1 AC A
N IC44 10074002 IC/MOS XC62EP1902MR 1 1 AC A
N IC43 10074003 IC/MOS XC6365A363MR 1 1 AG A
IC40 10007012 IC MB3800PF 1 1 AO A
N IC30 10074004 IC/RESET S-80130CNMC-JKP-T2 1 1 AC A
N IC39 10074005 IC SN751178NSR 1 1 BG A
N IC34,35,38,41,42 10074006 IC SN75188PWR 5 5 AF A
N IC31-33,36,37 10074007 IC SN75189APWR 5 5 AF A
F2,3 30008079 FUSE 430.500 2 2 AD A
F1 30007777 FUSE 230.600 1 1 AE A
D11,14 23902058 DIODE 1SR154-400TE25 2 2 AB B
D9,10,19,20 30007959 DIODE 1SS376TE-17 4 4 AA B
N D12,13,17,26 10009218 DIODE 1SS400TE61 4 4 AA B
N D4 23900987 DIODE DAN202K-T146 1 1 AA B
D5-8 23900777 DIODE/CHIP ARRAY IMN10T-108 4 4 AB B
D18 23153115 DIODE/ZENER PTZTE-255.1B 1 1 AB B
D21-23 28953130 DIODE/SCHOTTKY BARRIER RB051L-40TE25 3 3 AC B
N D3,15,16,24,25 23903042 DIODE/SCHOTTKY BARRIER RB521S-30TE61 5 5 AA B
N D1,2 23903082 DIODE/SCHOTTKY BARRIER SB05-05CP-TB 2 2 AB B
N Q6 10076309 TRANSISTOR 2SA1729S-TD 1 1 AC B
N Q9 10076310 TRANSISTOR 2SA2012-TD 1 1 AC B
N Q3,4 10076311 TRANSISTOR 2SD1626-TD 2 2 AC B
N Q7 10077387 TRANSISTOR 2SK1920-TL. 1 1 AM B
N Q8 10074017 TRANSISTOR XP162A12A6PR 1 1 AF B
Q5 25902697 TRANSISTOR/DIGITAL DTC114EETL 1 1 AA B
Q1,2,10 22592674 TRANSISTOR/DIGITAL DTC114YETL 3 3 AA B
N R180 10059695 THERMISTOR/CHIP NTH5G16P33B103J07T 1 1 AA B
N L1 10074018 INDUCTOR/POWER CDRH104R220NC-T 1 1 AG B
N T1 10076313 TRANSFORMER/DC CEI128-001 1 1 AT B
N X1 10074020 X' TAL/CHIP MA406-8.25M-10P 1 1 AM B
N X2 10079022 X' TAL/CHIP MC306-12.5/10 1 1 AL B
N X5 10074503 CERALOCK/CHIP CSTCE8M00G55-R0 1 1 AB B
N X3 10074504 CERALOCK/CHIP CSTCR6M00G55-R0 1 1 AB B
N X4 10074505 CERALOCK/CHIP CSTCV12M6T54J-R0 1 1 AC B
N X6 10074506 CERALOCK/CHIP CSTCW20M0X53-R0 1 1 AC B
N RA13,15-17,39, 27958158 RESISTOR/CHIP NETWORK RAC1005-1014DJT 9 9 AA C
63-66
N RA7-12,24,35, 27975626 RESISTOR/CHIP NETWORK RAC1005-1034DJT 23 23 AA C
40-48,51-54,61,62
Q'ty
USA,Canada
and Germany
Other
Countries
- 93 -
