Casio QT-2100 Service Manual

N Item Code No. Parts Name Specification Price Rank
Code
N
21 10072959
CASE/HINGE LOWER
E240799-1
1 1
AD
C
N
22 10072974 KEYNOB/SLIDE E341219-1
2 2
AC
C
N 23 10072977 COVER/SCREW E341121-2 2 2 AC C
N 24 10073049 SHEET E441273-1 2 2 AA C
N 25 59000007
SCREW
3 X 15 ZMC-3 1 1 AA C
N 26 10073667
SCREW
4 X 14 ZMC-3 2 2 AA C
27 10077957
SCREW
3 X 4 PLASTIC 2 2 AA C
SCREW
3 X 5 ZMC-3 7 7 X
SCREW
3 X 8 NI 4 4 X
SCREW
2.6 X 8 ZMC-3 4 4 X
3. BUTTON BLOCK and UPPER BLOCK
33 10042392 COVER/REAR E140127B-2 1 1 BH C
N 34 10076271 SHEET PGM/E590 E240301B-7 1 1 AD A
35 62477309 RUBBER/CONTACT E580 E340446-1 4 4 AT A
36 62477204 SHEET/COMMON E580 E240296-1 1 1 AT A
37 62480898 SPACER/E580 E240297A-1 1 1 AM C
38 62477218 FPC/E580 E240298-1 1 1 AY C
N 39 62480770 BUTTON/DETECTION E440387A-1 4 4 AA B
40 10074460 PCB ASSY/E590-E41 E441345*1 1 1 BN C
N CN3 10073692 CONNECTOR 05FM-1.0ST 1 1 AB C
N CN2 10073693 CONNECTOR S32B-PHDSS 1 1 AF C
CN1 35005848 CONNECTOR HLEM26R-1 1 1 AC C
41 10074464 PCB ASSY/E590-E42 E441346*1 1 1 BU C
N CN1 10073692 CONNECTOR 05FM-1.0ST 1 1 AB C
SW1-4 30007931 SWITCH / PUSH ABU8112S 4 4 AF B
N 42 10073060 PLATE/INSULATION E4-2 E441300-1 1 1 AA C
N 43 10073046 CABLE/FFC JOINER E441270-3 1 1 AC C
N 44 10073067 CABLE SUB ASSY/KEY E441318-1 1 1 BB C
N 45 10072893 FRAME/KEYBOARD E140104A-2 1 1 BF C
N 46 10076264 HOLDER/KEYBOARD E240342A-2 1 1 AK C
N 47 10072968 KB CHASSIS SUB ASSY E341228*1 1 1 AY C
N 48 10072979 COVER/SWITCH E341223-1 1 1 AH C
49 55001683 SPACER/TAPPING CARD KGTS-4K 3 3 AC C
50 55001690 MAGNET B-MMC12 2 2 AN C
N 51 31206121 COACHING CLIP CS-2-U 1 1 AA C
55600368 TIE/INSULOCK T-18S 1 1 AA C
N 52 10042323 SHEET MENU E240301A-5 1 1 AD C
53 10042349 COVER/SHEET E240724-1 2 2 AY C
N 54 10073033 PLATE/E590-1 E440401A-9 1 1 AG C
N 55 10073034 PLATE/E590-2 E440401A-10 1 1 AG C
N 56 10073035 PLATE/E590-3 E440401A-11 1 1 AG C
N 57 10073036 PLATE/E590-4 E440401A-12 1 1 AG C
N 58 10072964 SHEET FRAME SUB ASSY/1-3 E341123A*5 1 1 BA C
N 59 10072965 SHEET FRAME SUB ASSY/2-4 E341123A*6 1 1 BA C
SCREW 3 X 5 ZMC-3 7 7 X
SCREW 3 X 6 ZMC-3 29 29 X
SCREW 3 X 8 PAI 8 ZMC-3 6 6 X
SCREW 3 X 6 ZMC-3 2 2 X
SCREW 3 X 8 NI 2 2 X
4. ARCNET IN-LINE BOARD
N 69 10074459 PCB ASSY/E590-ARC E441344*1 1 1 DN A
N IC1 10073682 IC HYC2488S 1 1 DG A
N SW1 10073694 SLIDE SWITCH SSSU011700 1 1 AF B
N C4 10073688 AL CAPACITOR RE3-16V470M 1 1 AA C
N CN2,3 10073685 CONNECTOR TM3RA-88 2 2 AZ C
N CN1 35016944 CONNECTOR B5B-PH-K-S 1 1 AA C
N 70 10073064 CABLE SUB ASSY/ARC-05 E441315-1 1 1 AE C
71 10005683 INLINE CONNECTOR SUB ASSY E440720*2 1 1 AF C
R1 REGISTOR/CHIP RD25SM10-6101J 1 1 X
R2,3 REGISTOR/CHIP R25-154-K-S 2 2 X
C1,C2 CAPACITOR/CHIP CERAMIC DEA1X3A180JC1B 2 2 X
C3 CAPACITOR/CHIP CERAMIC ECQ-V1H-104-JZW 1 1 X
N 10073666 SCREW 3 X 20 NI 2 2 AA C
USA,Canada
and Germany
Other
Countries
Q'ty
- 96 -
