Casio QV-2400UX User Manual

N
Item
Code No.
Parts Name
Specification
Applicable
Q
Price Code
R
KB-PCB
SW895
3412 1995
SWITCH/TACT
SKQRAA-T
Common
1
AB
C
SW896
3412 1995
SWITCH/TACT
SKQRAA-T
Common
1
AB
C
SW897
3412 1995
SWITCH/TACT
SKQRAA-T
Common
1
AB
C
SW898
3412 1995
SWITCH/TACT
SKQRAA-T
Common
1
AB
C
PW-PCB
CN100
3501 7091
CONNECTOR/PCB
53254-0310
Common
1
AA
X
CN103
3502 2437
CONNECTOR
52745-1690
Common
1
AC
X
D100
2390 2506
DIODE
RB060L-40-TE25
Common
1
AD
X
FU100
1001 2479
FUSE/CHIP
434.750
Common
1
AB
A
FU101
1000 9214
FUSE/CHIP
434001
Common
1
AB
A
FU102
1000 9214
FUSE/CHIP
434001
Common
1
AB
A
FU103
1003 4689
FUSE/CHIP
43401.5
Common
1
AB
A
JK100
3501 6755
JACK/POWER
HEC3600-010120
Common
1
AD
B
Q110
2254 0570
FET
SI2301DS-T1
Common
1
AE
X
Q115
2254 0570
FET
SI2301DS-T1
Common
1
AE
X
Q120
2795 8157
FET/CHIP
CPH6401-TL
Common
1
AE
X
Q121
2259 2715
TRANSISTOR/DIGITAL
DTC144EETL
Common
1
AA
X
Q130
2250 1596
TRANSISTOR/CHIP
SI2302DS-T1
Common
1
AE
X
VR135
2775 3465
RESISTOR/SEMIFIXED/CHIP
POZ2AN-1-503N-T00
Common
1
AA
X
VR136
2775 3465
RESISTOR/SEMIFIXED/CHIP
POZ2AN-1-503N-T00
Common
1
AA
X
Notes:
NEW:
New registration parts
Q:
Quantity used per unit
R:
Rank
- 37 -
