— 30 —
Operation Display Note
(After a few seconds)
MEMORY 3 WR2
4 READ2
1 WR1 5 DUMP
2 READ1 6 CHKSUM
EXECUTING!!
2
( or 4 )
COMPLETE!!
64KB
DATA ERROR!!
ADDRESS CORR RAM
XXXX XX XX
RAM error
If the displayed address
is within 0000-7FFF,
check LSI3.
If the displayed address
is within 8000-FFFF,
check LSI2.
MEMORY 3 WR2
4 READ2
1 WR1 5 DUMP
2 READ1 6 CHKSUM
6
ESC
TEST 2 MEMORY
MENU 3 KEY
4 BUZZER
1 DISP 5 I/F
MEMORY 3 WR2
4 READ2
1 WR1 5 DUMP
2 READ1 6 CHKSUM
MEMORY 3 WR2
4 READ2
1 WR1 5 DUMP
2 READ1 6 CHKSUM
$ 00001,00002,00004,00008,00010,
00020,00040,00080,00100,00200,
00400,00800,01000,02000,04000,
08000,10000
Check sum and XOR
of ROM (LSI4) is dis-
played.
Address of ROM (LSI4)
is display.
Normal
ESC
5
ESC
ESC
TY SZ SUM XOR
FE 0 128 E290 XXX
C3 A 64 XXXX XXX
To Next Page
