Casio SF-5300E Service Manual & Parts List

11. PARTS LIST
FOB Japan
N Item Code No. Parts Name Specification Q M N.R.Yen R
Unit Price
CHIP ON BOARD BONDIN
1 6413 3720 Chip on board bondin DB22AX3F00U*1 1 1 2,750 B
(This assembly contains the following available elements.)
C1~4,7,8,12~14 6511 7560 Chip capacitor CP001A432T8 9 20 7 C
N C5,6 6511 7510 Chip capacitor CP018F602A7 2 20 11 C
LSI1 6411 2051 L594TAB ass'y C312133A*2 1 1 970 B
LSI2 2011 8267 LSI (RAM) CXK58257ATM-10/12L 1 1 580 B
LSI3 2011 8274 LSI (RAM) CXK58257AYM-10/12L 1 1 580 B
N LSI4 2011 9268 LSI (ROM) uPD23C1001EAGZ-M05 1 1 370 B
N R11 6512 1420 Chip resistor CC0015D11T0 1 20 3 C
N R12 6410 9820 Chip resistor CC2005D11E5 1 20 28 C
N R3 6411 6130 Chip resistor CC0000D11E9 1 20 3 C
X1 6510 4550 Crystal BD0063P2509 1 5 55 B
MAIN KEY BOARD ASS'Y
6 6412 2730 Main key board ass'y DB22XX3100U*1 1 1 790 B
(This assembly contains the following available elements.)
6-1 6409 6300 Battery plate (+) EF01DB20102 2 20 16 X
6-2 6409 6310 Battery plate (-) EF02DB10100 2 20 16 X
C10 6511 7560 Chip capacitor CP001A432T8 1 20 7 C
C9,11 2803 6813 Capacitor CB0011341R3 2 20 22 C
D1 2390 2135 Diode BC20MA740T0 1 10 50 C
D2 6510 4940 Diode BC10MA71307 1 5 53 C
DET1 2105 3864 CMOS IC RH5VL46CA-T1 1 10 45 C
JC1 3501 6538 Jack HSJ1169-012010 1 5 56 C
Q1 6510 4760 Transistor BBX114YT103 1 20 27 C
R5 6512 1380 Chip resistor CC1801D11E7 1 20 3 C
R6 6512 1410 Chip resistor CC0473D11T3 1 20 3 C
N R7 6512 1370 Chip resistor CC0013D11T1 1 20 3 C
R8,9 6512 1360 Chip resistor CC0012D11T6 2 20 3 C
REG1 2105 3290 Regulator S-81253SGUP-DIJ-T1 1 5 60 C
COMPONENTS
N 2 6413 3730 Mylar sheet ELBDB222003 1 20 28 B
3 6412 3140 Heat seal FX21P250016 1 5 53 A
N 4 6413 3710 Hot melt film tape HGJ00008414 1 20 27 B
5 6412 2920 Overlay mylar EL4J0002102 1 10 29 X
7 6511 7160 Rubber insert LC120000102 1 20 17 B
8 6412 2890 Rubber key sheet LADB2210000 1 1 260 C
9 6512 0730 Hinge stopper EF15DB06102 2 20 27 X
10 6412 2880 Push button FB3DB221002 1 20 13 C
11 6412 3020 Upper case (KB) FAADB221009 1 1 130 X
N 12 6412 3050 Hinge (A) FC0DB281006 1 20 26 x
13 6512 1210 Pin FC002870000 2 20 9 X
14 6512 1220 Pin (L) FC002870018 2 20 16 X
15 6412 2910 Hinge (B) FC0DB222002 1 20 22 X
16 6412 2990 Hinge tape HGJ00008309 1 20 22 B
N 17 6413 3670 Display plate EL5J0005502 1 1 120 B
18 6412 3040 Upper case (DIS) FAADB222005 1 1 110 X
19 6412 3130 Heat seal FX200P40064 1 1 100 A
20 3335 5264 LCD CD792-TS 1 1 790 A
N 21 6412 8000 Sponge cushion FH100029402 2 20 15 C
22 6412 2900 Rubber key sheet LADB2220005 1 1 103 C
Notes: N – New parts R – A : Essential
M – Minimum order/supply quantity B : Stock recommended
R – Rank C : Others
Q – Quantity used per unit X : No stock recommended
— 35 —
