SE-G1/PCR-T273/SM-T274
– 34 –
PARTS LIST
1 DL-1335
2 DL-1844
3 DL-1845
123
1 10449184 CASE/MAIN/BK RJE504018-001V01 1 1 B
1 10449188 CASE/MAIN/WE RJE504018-002V01 1 B
2 10449185 LEVER/HOOK RJE504008-001V01 1 1 1 C
3 10384548 ROLLER/PLASTIC PB-19B2 4 4 4 B
4 10201068 LOCK/SPRING RJE500007-001V02 1 1 1 C
5 10194207 SPRING/PRESS E412137-001V02 1 1 1 C
6 10167366 RUBBER/PAD RJE501204-001V01 5 5 5 C
7 10080189 SUB ASSY/SOLENOID E341255*2 1 1 1 B
8 10260417 AXIS/LEVER HOOK RJE502184-001V01 1 1 1 C
9 10267909 SPRING/PLUNGER RJE502245-001V01 1 1 1 C
10 10449179 CASE/BILL COIN RJE504011-001V01 1 X
N 10 10449176 CASE/BILL COIN RJE504011-002V01 1 X
10 10449182 CASE/BILL COIN RJE504011-003V01 1 X
11 10231347 SUB ASSY/BILL HOLDER RJE501337*001V03 1 X
12 10194229 PLATE/BILL HOLDER E341289-001V02 1 1 X
13 10230104 BILL HOLDER SUB ASSY E341290*002V04 3 3 C
14 10276626 SPRING/BILL HOLDER E441357-001V03 4 3 3 X
15 10298553 PLATE/PARTITION RJE500214-002V03 3
22C
16 10298558 CASE/COIN RJE500212-002V04 1 1 1 C
17 10298552 SEPARATER/COIN RJE500213-002V03 4 4 4 C
18 10447858 LOCK/CYRINDER RJE502350*002V01 1 1 1 C
N 19 54400287 RIVETS/COLD HEADED 5X26 1 1 1 X
N 20 55801452 CS FIX CSTW-5 1 1 1 X
W1 WASHER 11.5X6.5XT0.8 2 2 2 X
S1 SCREW S-PAPT-3X8Z3 5 5 5 X
S2 SCREW S-PAST-3X5NI 3 3
Q'TY
RSpecificationN Item Code No. Parts Name
