Casio TE-2000 Service Manual

— 6 —
3. 1 Remove two screws.
2 Slide the KEY UNIT to front side and lift it up.
Then remove one FPC (CN13).
12
3
■PRINTER UNIT
1. Remove the upper cover as shown in steps 1 to 3 of page 5.
2. Remove the pully.
3. Lift up the printer unit cover as Fig.
4. Remove the battery cover.
CN13
( Fig)
Screws
1
2

Casio TE-2000 Specifications

General

Brand	Casio
Model	TE-2000
Category	Cash Register
Language	English
