Casio TE-8000F Service Manual

TE-7000S
N
Item
Code No.
Parts Name
Specification
Price
R
Code
Europe UK USA
1. MAIN PCB BLOCK
N 1 10104430 PCB ASSY/E468-1 RJE500408*1 1 1 1 1 1 1 1 EJ A
N IC33 10100136 LSI HD6417706F133 1 1 1 1 1 1 1 CK A
N IC21 10111217 LSI UPD784215AGC8028EU 1 1 1 1 1 1 1 BN A
IC10 10073986 LSI UPD65945GJ-P16-JEU 1 1 1 1 1 1 1 BU A
N IC19 10103458 LSI MBM29DL324BE90TNAA 1 1 1 1 1 1 1 BW A
N IC18 10100310 LSI MD56V62160E-10TAB0 1 1 1 1 1 1 1 BU A
N IC13 10100311 LSI S1D13705F00A100 1 1 1 1 1 1 1 CF A
IC11 10006024 LSI COM20019ILJP 1 1 1 1 1 1 1 CF A
IC35,36 21120788 IC L6219DS 2 2 2 2 2 2 2 BC A
N IC20 10105416 IC/CMOS SN74AHCT08PWR 1 1 1 1 1 1 1 A
IC16 10003984 IC/CMOS SN74LV00APWR 1 1 1 1 1 1 1 AB A
N IC32 10105417 IC/CMOS SN74LV07APWR 1 1 1 1 1 1 1 AA A
IC31,34 10005659 IC/CMOS SN74LV08APWR 2 2 2 2 2 2 2 AB A
IC15 10007179 IC/CMOS SN74LV10APWR 1 1 1 1 1 1 1 AC A
IC8 21056580 IC/CMOS SN74LV14APWR 1 1 1 1 1 1 1 AC A
IC9 10005721 IC/CMOS SN74LV244APWR 1 1 1 1 1 1 1 AF A
N IC27,28 10105407 IC/CMOS SN74LVC244APWR 2 2 2 2 2 2 2 AA A
N IC29,30 10105408 IC/CMOS SN74LVC245APWR 2 2 2 2 2 2 2 AA A
N IC22 10105409 IC/CMOS SN74LVU04APWR 1 1 1 1 1 1 1 AD A
IC6 10074001 IC/MOS XC6201P192MR 1 1 1 1 1 1 1 AC A
IC5 10074002 IC/MOS XC62EP1902MR 1 1 1 1 1 1 1 AC A
IC4 10074003 IC/MOS XC6365A363MR 1 1 1 1 1 1 1 AG A
IC17 21120763 IC/RESET M51957BFP-T1 1 1 1 1 1 1 1 AJ A
IC14 10074005 IC SN751178NSR 1 1 1 1 1 1 1 BG A
IC1-3 21120820 IC HIN211CA-T 3 3 3 3 3 3 3 AT A
IC7,39 21120821 IC BA10393F-E2 2 2 2 2 2 2 2 AB A
R1-9,51,53,86,87, RESISTOR/CHIP RC1608-000-T 20 20 20 20 20 20 20 X
163,-166,168,170,
176
R128,130,137,138, RESISTOR/CHIP RC1608-100-J-T 4 4 4 4 4 4 4 X
R84,85,99,109, RESISTOR/CHIP RC1608-101-J-T 8 8 8 8 8 8 8 X
152,153,155,156
R18,24,30,34,68, RESISTOR/CHIP RC1608-102-J-T 12 12 12 12 12 12 12 X
71,113,114,129,
136,142,162
R10,16,17,19-22, RESISTOR/CHIP RC1608-103-J-T 29 29 29 29 29 29 29 X
25-27,43,44,89,92,
97,110,127,133,
141,146,150,151,
154,157-160,169,
182
R95,140 RESISTOR/CHIP RC1608-104-J-T 2 2 2 2 2 2 2 X
R67,183 RESISTOR/CHIP RC1608-105-J-T 2 2 2 2 2 2 2 X
R47,48,54,55,59, RESISTOR/CHIP RC1608-123-J-T 8 8 8 8 8 8 8 X
60,64,65
R46,52,58,63 RESISTOR/CHIP RC1608-202-J-T 4 4 4 4 4 4 4 X
R12,15,23,31,35, RESISTOR/CHIP RC1608-203-J-T 7 7 7 7 7 7 7 X
134,135
R112 RESISTOR/CHIP RC1608-222-J-T 1 1 1 1 1 1 1 X
R13 RESISTOR/CHIP RC1608-331-J-T 1 1 1 1 1 1 1 X
R115-126,184 RESISTOR/CHIP RC1608-332-J-T 13 13 13 13 13 13 13 X
R73-83,90,91,96, RESISTOR/CHIP RC1608-470-J-T 16 16 16 16 16 16 16 X
108,132
R42,45,50,57,62, RESISTOR/CHIP RC1608-472-J-T 12 12 12 12 12 12 12 X
94,98,111,139,
144,167,174
R49,56,61,66,72, RESISTOR/CHIP RC1608-563-J-T 9 9 9 9 9 9 9 X
88,143,149,178
R103,107 RESISTOR/CHIP RC210-271-J-T 2 2 2 2 2 2 2 X
R28,29,32,34 RESISTOR/CHIP RC633-3R6-J-T 4 4 4 4 4 4 4 X
R40,100,105 RESISTOR/CHIP RC1608-1002-F-T 3 3 3 3 3 3 3 X
R101,104 RESISTOR/CHIP RC1608-1003-F-T 2 2 2 2 2 2 2 X
Q'ty
Europe UK
USA/
Canada
Australia
Other Countries
Plug Type
- 108 -
