Casio TE-8000F Service Manual

N
Item
Code No.
Parts Name
Specification
Price
R
Code
Europe UK USA
Q'ty
Europe UK
USA/
Canada
Australia
Other Countries
Plug Type
R145 RESISTOR/CHIP RC1608-3001-F-T 1 1 1 1 1 1 1 X
R147,185 RESISTOR/CHIP RC1608-4702-F-T 2 2 2 2 2 2 2 X
R41 RESISTOR/CHIP RC1608-5602-F-T 1 1 1 1 1 1 1 X
R14 RESISTOR/CHIP RC315-15R0-F-T 1 1 1 1 1 1 1 X
N RM19,20 26601173 RESISTOR/CHIP NETWORK RAC1608-0004DJT 2 2 2 2 2 2 2 AA C
RM1,2,5,9,10,18, 26601156 RESISTOR/CHIP NETWORK RAC1608-1034DJT 38 38 38 38 38 38 38 AA C
29-33,44,51-53,57,
58,60,61,64,66,68,
70,75-82,90,92-94,
96,110,111
N RM59,102-104 26601160 RESISTOR/CHIP NETWORK RAC1608-1044DJT 4 4 4 4 4 4 4 AA C
N RM8,13-17,25-28, 27957901 RESISTOR/CHIP NETWORK RAC1608-3304DJT 22 22 22 22 22 22 22 AA C
34-38,41-43,45-48
RM23,24,39,40,71- 10005641 RESISTOR/CHIP NETWORK RAC1608-4704DJT 12 12 12 12 12 12 12 AA C
74,83-86
RM3,4,6,7,21,22, 26523047 RESISTOR/CHIP NETWORK RAC1608-5634DJT 16 16 16 16 16 16 16 AA C
54-56,69,87-89,91,
95,107
C50,51 CAPACITOR/CHIP GRM1882C1H9R0DZ01D 2 2 2 2 2 2 2 X
C15-19,21,24-26, CAPACITOR/CHIP GRM1882C1H101JA01D 19 19 19 19 19 19 19 X
48,58,84,90,99,
100,123,127,133,
134
C80,81 CAPACITOR/CHIP GRM1882C1H150JA01D 2 2 2 2 2 2 2 X
C13,14,49,147 CAPACITOR/CHIP GRM188B10J105KA01D 4 4 4 4 4 4 4 X
C126 CAPACITOR/CHIP GRM188B11A334KA61D 1 1 1 1 1 1 1 X
C1,3,4,6,20,22,27, CAPACITOR/CHIP GRM188B11E104KA01D 66 66 66 66 66 66 66 X
40,46,52,55,71-77,
82,86,91-93,95,97,
101-122,125,128-
132,135-146,154
C94,96,98 CAPACITOR/CHIP GRM21BB11H104KA01L 3 3 3 3 3 3 3 X
C124 CAPACITOR/CHIP GRM188B11E473KA01D 1 1 1 1 1 1 1 X
C28,29,33,34 CAPACITOR/CHIP GRM188B11H472KA01D 4 4 4 4 4 4 4 X
N CM1-4 28456609 CAPACITOR/CHIP MODULE CAF13CG101K50AT 4 4 4 4 4 4 4 AA C
C12 77201631 CAPACITOR/CHIP TANTALUM SK4-0J106M-RA 1 1 1 1 1 1 1 AA C
C10,39,79 28953056 CAPACITOR/CHIP TANTALUM SK4-1A107M-RD0 3 3 3 3 3 3 3 AE C
C11 28952541 CAPACITOR/CHIP TANTALUM SK5-1A106M-RA 1 1 1 1 1 1 1 AA C
C47 10074012 CAPACITOR/ELECTROLYTIC RV-16V471MH10-R 1 1 1 1 1 1 1 AC C
C30,35 28077818 CAPACITOR/ELECTROLYTIC RV-35V101MG10-R 2 2 2 2 2 2 2 AB C
N C2,5 28077869 CAPACITOR/ELECTROLYTIC RV2-16V100MB55-R 2 2 2 2 2 2 2 AA C
C9,41,45,54,67,78 28073647 CAPACITOR/ELECTROLYTIC RV2-16V101MS-R 6 6 6 6 6 6 6 AA C
C7,87 28077106 CAPACITOR/ELECTROLYTIC RV2-35V100M-R 2 2 2 2 2 2 2 AA C
C88 28073626 CAPACITOR/ELECTROLYTIC RV3-10V221MF80-R 1 1 1 1 1 1 1 AB C
D22,24,26,28 23902058 DIODE/CHIP 1SR154-400TE25 4 4 4 4 4 4 4 AB B
D16-19 30007959 DIODE/CHIP 1SS376TE-17 4 4 4 4 4 4 4 AA B
D14,21,23,25,27 10009218 DIODE/CHIP 1SS400TE61 5 5 5 5 5 5 5 AA B
D15 23153115 DIODE/CHIP ZENER PTZTE-255.1B 1 1 1 1 1 1 1 AB B
D1-9,11 28953130 DIODE/CHIP RB051L-40TE25 10 10 10 10 10 10 10 AC B
D10,12,13,29,30 23903042 DIODE/CHIP RB521S-30TE61 5 5 5 5 5 5 5 AA B
Q12 10076309 TRANSISTOR 2SA1729S-TD 1 1 1 1 1 1 1 AC B
Q4 10076310 TRANSISTOR 2SA2012-TD 1 1 1 1 1 1 1 AC B
Q6-9 10076311 TRANSISTOR 2SD1626-TD 4 4 4 4 4 4 4 AC B
N Q1 10091501 TRANSISTOR FSS134-TL 1 1 1 1 1 1 1 AQ B
Q5 10074017 TRANSISTOR XP162A12A6PR 1 1 1 1 1 1 1 AF B
Q11 25902697 TRANSISTOR/DIGITAL DTC114EETL 1 1 1 1 1 1 1 AA B
Q2,3,10 22592674 TRANSISTOR/DIGITAL DTC114YETL 3 3 3 3 3 3 3 AA B
L1 10074018 INDUCTOR CDRH104R220NC-T 1 1 1 1 1 1 1 AG B
X6 10074020 X' TAL/CHIP MA406-8.25M-10P 1 1 1 1 1 1 1 AM A
X1 10074503 CERALOCK/CHIP CSTCE8M00G55-R0 1 1 1 1 1 1 1 AB A
N X5 10111104 CERALOCK/CHIP CSTCE10M0G55-R0 1 1 1 1 1 1 1 AC A
N X3 10111105 CERALOCK/CHIP CSTCE16M0V53-R0 1 1 1 1 1 1 1 AC A
N X2 10111106 CERALOCK/CHIP CSTCW20M0X53-R0. 1 1 1 1 1 1 1 AC A
- 109 -

Casio TE-8000F Specifications

General

Brand	Casio
Model	TE-8000F
Category	Cash Register
Language	English
