Casio TE-8000F Service Manual

N
Item
Code No.
Parts Name
Specification
Price
R
Code
Europe UK USA
Q'ty
Europe UK
USA/
Canada
Australia
Other Countries
Plug Type
FU2,3 30008079 FUSE/CHIP 430.500 2 2 2 2 2 2 2 AD A
CN15 10074027 CONNECTOR AXN380130P 1 1 1 1 1 1 1 BE C
CN9 77401603 CONNECTOR B2B-PH-SM3-TB 1 1 1 1 1 1 1 AC C
CN25 35019394 CONNECTOR B2B-ZR-SM3-TF 1 1 1 1 1 1 1 AB C
CN11-14 35021809 CONNECTOR B3B-PH-SM3-TB 4 4 4 4 4 4 4 AC C
CN22 35021340 CONNECTOR B4B-ZR-SM3-TF 1 1 1 1 1 1 1 AB C
CN5 35018645 CONNECTOR B5B-PH-SM3-TB 1 1 1 1 1 1 1 AC C
CN17 35017546 CONNECTOR B5B-ZR-SM3-TF 1 1 1 1 1 1 1 AC C
N CN18 35019765 CONNECTOR B12B-ZR-SM3-TF 1 1 1 1 1 1 1 AD C
N CN3 10105405 CONNECTOR HFW25S-2STE1 1 1 1 1 1 1 1 AK C
N CN20 10105403 CONNECTOR 62451-022L 1 1 1 1 1 1 1 BL C
SW1 10004466 SLIDE SWITCH SSSS823-B-3B 1 1 1 1 1 1 1 AF C
N CN4 69302476 CONNECTOR B7B-PH-SM3-TB 1 1 1 1 1 1 1 AF C
N IC37 10005307 IC/CMOS SN74AHC1G08DCKR 1 1 1 1 1 1 1 AA A
R177 RESISTOR/CHIP RC1608-330-J-T 1 1 1 1 1 1 1 X
R131 RESISTOR/CHIP RC1608-681-J-T 1 1 1 1 1 1 1 X
R186 RESISTOR/CHIP RC1608-1802-F-T 1 1 1 1 1 1 1 X
C23,31,36,37 CAPACITOR/CHIP GRM1882C1H271JA01D 4 4 4 4 4 4 4 X
N C32,89 10047458 CAPACITOR/ELECTROLYTIC RV3-6V331MF80-R 2 2 2 2 2 2 2 AB C
C148 CAPACITOR/CHIP GRM1882C1H102JA01D 1 1 1 1 1 1 1 X
X4 10094206 X' TAL/CHIP C-002RX-8.3/10 1 1 1 1 1 1 1 AF A
N R36 10108809 RESISTOR/METAL OXIDE ERX1SJ5R6P 1 1 1 1 1 1 1 AA C
C38 10073679 CAPACITOR/ELECTROLYTIC RE3-50V102M-T4 1 1 1 1 1 1 1 AD C
FU1 30007777 FUSE 230.600 1 1 1 1 1 1 1 AE A
CN6 35005846 CONNECTOR 53253-0210 1 1 1 1 1 1 1 AA C
CN19 35017728 CONNECTOR B14B-PHDSS 1 1 1 1 1 1 1 AB C
CN21 35802364 CONNECTOR B30B-PHDSS 1 1 1 1 1 1 1 AE C
N CN8 35018288 CONNECTOR B3P-VH 1 1 1 1 1 1 1 AB C
N CN1,2 10105399 CONNECTOR HLEM25S-1 2 2 2 2 2 2 2 AC C
CN7 10073680 CONNECTOR IMSA-9202B-1-03P-T 1 1 1 1 1 1 1 AA C
SP1 32402089 BUZZER PKM22EPT-2001 1 1 1 1 1 1 1 AE C
SW2 10073681 SLIDE SWITCH SSSU141500 1 1 1 1 1 1 1 AJ C
N 10105400 SOCKET IMSA-9206H-T 1 1 1 1 1 1 1 AA C
SCREW S-PAMA-2X6ZC 2 2 2 2 2 2 2 X
2. LCD block
N 2
10104449 CASE/LCD-F E468 RJE500319-1
1 1 1 1 1 1 1
BD C
N 3
10104450 CASE/LCD-R E468 RJE500320-1
1 1 1 1 1 1 1
BD C
N 4
10104455 SHEET/DISPLAY RJE500390-1
1 1 1 1 1 1 1
AS C
N 5
10104452 SLIDE KNOB E468 RJE500322-1
1 1 1 1 1 1 1
AB C
N 6
10113417 LCD UNIT KCG057QV1DB-G00
1 1 1 1 1 1 1
EA A
N 7
10104448 INVERTER/CFL PS2-70052-001
1 1 1 1 1 1 1
CL A
8
10042373 HINGE/HEXA TORQ KH62B075L
1 1 1 1 1 1 1
BT C
N 9
10104461 PCB ASSY/E468-E2-CL RJE500425*1
1 1 1 1 1 1 1
BA A
R2-9,12-15 RESISTOR/CHIP MCR03EZHJ470
12 12 12 12 12 12 12
X
R10 RESISTOR/CHIP MCR03EZHJ153
1 1 1 1 1 1 1
X
R11 RESISTOR/CHIP MCR03EZHJ183
1 1 1 1 1 1 1
X
R16,TH1 RESISTOR/CHIP MCR03EZHJ000
2 2 2 2 2 2 2
X
N
CN1 10069249 CONNECTOR S12B-ZR-SM3A-TF
1 1 1 1 1 1 1
AD C
N
CN2 79300427 CONNECTOR SFV20R-1STE1
1 1 1 1 1 1 1
AC C
N
CN3 35020199 CONNECTOR S5B-ZR-SM3A-TF
1 1 1 1 1 1 1
AC C
N
VR1 10105428 SLIDE VOLUME RS15T11AA000
1 1 1 1 1 1 1
AD C
N 10
10104456 CABLE/FFC JOINER E468 RJE500391-1
1 1 1 1 1 1 1
AE C
N 11
10111055 LCD CABLE SUB ASSY RJE500385*1
1 1 1 1 1 1 1
AT C
N 12
10111056 LCD CABLE SUB ASSY RJE500385*2
1 1 1 1 1 1 1
AK C
N 13
10111057 LCD CABLE SUB ASSY RJE500385*3
1 1 1 1 1 1 1
AG C
SCREW S-PAPT-3X8ZC
4 4 4 4 4 4 4
X
N 14
10114076 PANEL/LCD E468 RJE500444-1
1 1 1 1 1 1 1
BT C
N
10114077 CUSION/LCD V-E468 RJE500371-1
2 2 2 2 2 2 2
AA X
N
10114078 CUSION/LCD H-E468 RJE500373-1
2 2 2 2 2 2 2
AA X
TIE/INSULOCK T-18S
1 1 1 1 1 1 1
X
N 15
10114079 CHASSIS/LCD E468 RJE500482-1
1 1 1 1 1 1 1
AL C
SCREW S-WBPT-3X8ZC
4 4 4 4 4 4 4
X
SCREW S-PAMA-3X6B
4 4 4 4 4 4 4
X
- 110 -
