Casio TE-8000F Service Manual

N
Item
Code No.
Parts Name
Specification
Price
R
Code
Europe UK USA
Q'ty
Europe UK
USA/
Canada
Australia
Other Countries
Plug Type
SCREW S-PASEMA-4X5ZC
1 1 1 1 1 1 1
X
SCREW
S-PASEMA-3X6ZC 2 2 2 2 2 2 2 X
N 10115091
FG CABLE SUB ASSY
RJE500484*1 1 1 1 1 1 1 1 AB C
N 16 10113436 HOLDER/HINGE E468 RJE500441-1 1 1 1 1 1 1 1 AD C
N 10114087 SHEET/BLIND E468 RJE500443-1 1 1 1 1 1 1 1 C
3. Customer Display block
N 17 10104422
CASE/RDP E468
RJE500324-1 1 1 1 1 1 1 1 AS C
N 18 10104421
PANEL/RDP E468
RJE500323-1 1 1 1 1 1 1 1 AT B
19 43081401
PCB/E445A-E2-2
E340800-1 1 1 1 1 1 1 1 AF X
LED3-7 23201365 LED/7SEG HDSP-5621#S02 5 5 5 5 5 5 5 AP B
LED1,2 24088398 LED GL8EG42 2 2 2 2 2 2 2 AA B
CN2 35405193 CONNECTOR HLW10R-2C7 1 1 1 1 1 1 1 AB C
CN1 35405194 CONNECTOR HLW12R-2C7 1 1 1 1 1 1 1 AB C
N 20 10104445 CABLE/C E468 E440657-12 1 1 1 1 1 1 1 AF C
N 21 10114075 CABLE/D E468 E440657-13 1 1 1 1 1 1 1 AG C
N
10115537
CUSION/A E468
RJE500539-1
1 1 1 1 1 1 1
AA
X
4. Button block
22 62481255 FRAME/KB E445 E140249-1 1 1 1 1 1 1 1 AU C
23 62467810 KETTOP/S E311101A-4 72 72 72 72 72 72 72 AA B
24 62467768 KETTOP/L E210963A-4 3 3 3 3 3 3 3 AD B
25 62210371 CAP/S E311103A-1 60 60 60 60 60 60 60 AA B
26 62213988 CAP/L E210964-1 3 3 3 3 3 3 3 AB B
27 62457250 BUTTON/1 E311792-1 1 1 1 1 1 1 1 AB C
28 62457260 BUTTON/2 E311792-2 1 1 1 1 1 1 1 AB C
29 62457270 BUTTON/3 E311792-3 1 1 1 1 1 1 1 AB C
30 62457280 BUTTON/4 E311792-4 1 1 1 1 1 1 1 AB C
31 62457290 BUTTON/6 E311792-5 1 1 1 1 1 1 1 AB C
32 62457300 BUTTON/7 E311792-6 1 1 1 1 1 1 1 AB C
33 62457310 BUTTON/8 E311792-7 1 1 1 1 1 1 1 AB C
34 62457320 BUTTON/9 E311792-8 1 1 1 1 1 1 1 AB C
35 62457330 BUTTON/0 E311792-9 1 1 1 1 1 1 1 AB C
36 62457340 BUTTON/. E311792-10 1 1 1 1 1 1 1 AB C
37 62457350 BUTTON/00 E311792-11 1 1 1 1 1 1 1 AB C
38 62457360 BUTTON/5 E311116-4 1 1 1 1 1 1 1 AB C
39 62471478 BUTTON FILLER E311197-2 4 4 4 4 4 4 4 AB C
40 62480990 RUBBER/CONTACT E411877A-1 75 75 75 75 75 75 75 AA B
41 62473830 SPRING/COIL E411104A-1 3 3 3 3 3 3 3 AA B
SCREW S-WBPT-3X8ZC 10 10 10 10 10 10 10 X
42 62473837 SPRING/COIL E411104A-2 7 7 7 7 7 7 7 AA B
43 62481750 FPC/E445 E240507A-1 1 1 1 1 1 1 1 BF B
44 62481294 SHEET/COMMON E340737-1 1 1 1 1 1 1 1 AV B
45 62481295 SPACER/E445 E340738-1 1 1 1 1 1 1 1 AF C
46 62481296 CHASSIS/KB E445 E340739-1 1 1 1 1 1 1 1 AK C
%- PLATE/S E240526-6 1 1 1 1 1 1 1 X
- PLATE/S E240526-7 1 1 1 1 1 1 1 X
5 PLATE/S E240526-25 1 1 1 1 1 1 1 X
6 PLATE/S E240526-26 1 1 1 1 1 1 1 X
7 PLATE/S E240526-27 1 1 1 1 1 1 1 X
8 PLATE/S E240526-28 1 1 1 1 1 1 1 X
9 PLATE/S E240526-29 1 1 1 1 1 1 1 X
10 PLATE/S E240526-30 1 1 1 1 1 1 1 X
11 PLATE/S E240526-31 1 1 1 1 1 1 1 X
12 PLATE/S E240526-32 1 1 1 1 1 1 1 X
13 PLATE/S E240526-33 1 1 1 1 1 1 1 X
14 PLATE/S E240526-34 1 1 1 1 1 1 1 X
15 PLATE/S E240526-35 1 1 1 1 1 1 1 X
16 PLATE/S E240526-36 1 1 1 1 1 1 1 X
17 PLATE/S E240526-37 1 1 1 1 1 1 1 X
18 PLATE/S E240526-38 1 1 1 1 1 1 1 X
19 PLATE/S E240526-39 1 1 1 1 1 1 1 X
20 PLATE/S E240526-40 1 1 1 1 1 1 1 X
21 PLATE/S E240526-41 1 1 1 1 1 1 1 X
22 PLATE/S E240526-42 1 1 1 1 1 1 1 X
- 111 -
