Casio TE-8000F Service Manual

N
Item
Code No.
Parts Name
Specification
Price
R
Code
Europe UK USA
Q'ty
Europe UK
USA/
Canada
Australia
Other Countries
Plug Type
23 PLATE/S E240526-43 1 1 1 1 1 1 1 X
24 PLATE/S E240526-44 1 1 1 1 1 1 1 X
1 PLATE/S E240526-57 1 1 1 1 1 1 1 X
2 PLATE/S E240526-58 1 1 1 1 1 1 1 X
3 PLATE/S E240526-59 1 1 1 1 1 1 1 X
4 PLATE/S E240526-60 1 1 1 1 1 1 1 X
RECEIPT FEED PLATE/S E240526-61 1 1 1 1 1 1 1 X
JOURNAL FEED PLATE/S E240526-62 1 1 1 1 1 1 1 X
RECEIPT PLATE/S E240526-63 1 1 1 1 1 1 1 X
MEDIA CHANGE PLATE/S E240526-65 1 1 1 1 1 1 1 X
#/NS PLATE/S E240526-66 1 1 1 1 1 1 1 X
RF PLATE/S E240526-67 1 1 1 1 1 1 1 X
C PLATE/S E240526-69 1 1 1 1 1 1 1 X
OPEN PLATE/S E240526-71 1 1 1 1 1 1 1 X
RC PLATE/S E240526-73 1 1 1 1 1 1 1 X
CR1 PLATE/S E240526-75 1 1 1 1 1 1 1 X
CR2 PLATE/S E240526-76 1 1 1 1 1 1 1 X
CHK/TEND PLATE/S E240526-78 1 1 1 1 1 1 1 X
PD PLATE/S E240526-83 1 1 1 1 1 1 1 X
NEW/OLD CHK PLATE/S E240526-88 1 1 1 1 1 1 1 X
NB PLATE/S E240526-92 1 1 1 1 1 1 1 X
CANCEL PLATE/S E240526-108 1 1 1 1 1 1 1 X
X PLATE/S E240526-109 1 1 1 1 1 1 1 X
VOID PLATE/S E240526-110 1 1 1 1 1 1 1 X
YES PLATE/S E240526-111 1 1 1 1 1 1 1 X
NO PLATE/S E240526-112 1 1 1 1 1 1 1 X
PAGE DOWN PLATE/S E240526-113 1 1 1 1 1 1 1 X
PAGE UP PLATE/S E240526-114 1 1 1 1 1 1 1 X
HOME PLATE/S E240526-115 1 1 1 1 1 1 1 X
-> PLATE/S E240526-118 4 4 4 4 4 4 4 X
COVERS PLATE/S E240526-89 1 1 1 1 1 1 1 X
TABLE TRANS PLATE/S E240526-90 1 1 1 1 1 1 1 X
PRICE PLATE/S E240526-122 1 1 1 1 1 1 1 X
LIST# PLATE/S E240526-123 1 1 1 1 1 1 1 X
CH PLATE/S E240526-77 1 1 1 1 1 1 1 X
MENU SHIFT PLATE/S E240526-125 1 1 1 1 1 1 1 X
ESC/SKIP PLATE/S E240526-126 1 1 1 1 1 1 1 X
PLU PLATE/L E240527-1 1 1 1 1 1 1 1 X
SUB TOTAL PLATE/L E240527-21 1 1 1 1 1 1 1 X
CA/AMT TEND PLATE/L E240527-23 1 1 1 1 1 1 1 X
5. Power supply block
47 62214802 CORD/POWER M2511 1 1 BC C
48 37010242 CORD/POWER MP5004 1 1 BO C
49 37004283 CORD/POWER M3203 1 AZ C
50 10023027 CORD/POWER PS204-A 1 1 AR C
N 51 10104443 POWER SUPPLY SPS-468 1 1 1 1 1 1 1 DN A
N 94870806 FUSE 213 3.15 1 1 1 1 1 1 1 A
CONNECTOR CE2 1 1 1 1 1 1 1
6. Upper case block
N 52 10104622 BUSH/RDP E468 RJE500339-1 1 1 1 1 1 1 1 AC C
SCREW S-WBPT-3X20ZC 2 2 2 2 2 2 2 X
SCREW S-WBPT-3X8ZC 19 19 19 19 19 19 19 X
N 10104383 SHEET/INSULATOR RJE500396-1 1 1 1 1 1 1 1 AB C
N 53 10104384 KEYTOP/F RJE500397-1 1 1 1 1 1 1 1 AE B
N 54 10104386 RUBBER/CONTACT RJE500398-1 1 1 1 1 1 1 1 AI B
N 55 10115540 CHASSIS/MODE KEY RJE500481-1 1 1 1 1 1 1 1 BL C
N 56 10104388 CASE/DISPLAY RJE500406-1 1 1 1 1 1 1 1 BJ C
N 57 10111059 KEY CABLE SUB ASSY RJE500388*1 1 1 1 1 1 1 1 BN C
N 58 10111063 KEY CABLE SUB ASSY RJE500388*2 1 1 1 1 1 1 1 BF C
N 59 10104390 COVER/HINGE RJE500429-1 1 1 1 1 1 1 1 AO C
N 60 10113482 CASE/UPPER RJE500442-1 1 1 1 1 1 1 1 AV C
SCREW S-PASEMA-3X6ZC 2 2 2 2 2 2 2 X
SCREW S-PASEMA-4X5ZC 3 3 3 3 3 3 3 X
- 112 -
