— 43 —
No Device to be checked Operation Note Page
1 Batch test 1 2
Test Device : RAM, Flash, Printer,
44
Date, Time, Buzzer, Drawer
2 Batch test 2 3
Test Device : LCD, Back light,
45
Rear Display
3 RAM WRITE/READ test n011 46
4 RAM READ ONLY test n111 46
5 FLASH CHECK SUM n512 47
6
FLASH CLEAR &
n612 47
WRITE/READ test (no BACK UP)
7 CF-CARD WRITE/READ test pn013 48
8 CF-CARD READ ONLY test pn113 48
9 CF-CARD CLEAR test pn213 49
10
CF-CARD CLEAR WRITE/READ test
pn313 49
11 LCD display test n021 50
12 LCD backlight OFF test 121 51
13 REAR DISPLAY test n122 51
14 REMOTE DISPLAY test na23 52
15 External printer print test x1x2x3n03d 53
16 Internal printer print test cn03d 54
17 Internal printer graphic print test
P1P1P1P2P2P2n13d
55
18 Internal printer dot rate test pn33d 56
19 Internal printer print density test x0235 57
20 RS232C PORT test xN04d 57
21 RS232C PORT batch test 40 58
22 ARCNET test rllmmx0a51 59
23 ARCNET batch tes 150/250 60
24 Time setting
x1x2x3x4x5x60a70
61
25 Time display 70 61
26 Drawer open test xn091 61
27 Buzzer test n092 62
28 KEY dipsplay 94 63
29 OBR test 95 64
9-6. Check item
The following test can be checked in the diagnostic test.
