Casio V-R100 Service Manual

V-R100
– 27 –
2. Test items
Test items Note Page
DIAG MENU
0 Display Version Number Displays version numbers of DIAG and IOC. P22
1 TP For testing the touch panel P22
2 Set Log File Number
For setting log le number
*Not used
P22
3 Batch 1
Tests clock, ROM, RAM and drawer automatically
To be prepared: Drawer
P22
4 Status For testing switches and sensors P23
5 Main LCD For testing LCD P23
6 Initialize eMMC
To initialize eMMC so that it can read and write
*Not used
P24
SD/eMMC/USB/LAN MENU
1 SD - vsd command For cheking SD card P24
2 eMMC - vem command To check eMMC ash memory P24
3 USB memory - vus command
For cheking USB memory
To be prepared: USB memory
P24
4 LAN - lanp command
For testing the communications of LAN connected
devices
To be prepared: Onother unit, LAN cable
P25
IOC MENU
1 IPL CG
Writes data in CG ROM
*Do not execute this menu item unless you are
specically asked to do so.
P25
2 Rear LCD To check rear LCD P25
3 COM1/2/3 Loopback
For testing COM port
To be prepared: Loopback connector
P26
4 MCR
To check MCR
*Not used
P26
5 Dallas
To check dallas key
*Not used
P26
6 Drawer #1 and #2
To check drawer
To be prepared: Drawer
P27
7 Printer For checking built-in printer P27
Other MENU
1 Print LOG Prints the test log P28
2 MAC ADDRESS Menu
Displays/corrects MAC address
*Not used
P28
3 Show Serial Number
Displays the serial number
*Not used
P28
4 Write Serial Number
Writes the serial number
*Not used
P28
5 Charge ON For testing charge ON P29
6 Charge OFF For testing charge OFF P29
7 Time Display Indicates the present time P29
8 LED For checking LEDs P29
9 IPL eMMC
Writes diagnostic program in eMMC ash memory
*Not used
P30
10 command
Test execution by DIAG command
*Not used
P30
