V-R100
– 28 –
DIAG MENU
0. Display Version Number
[Function]
Indicates the version numbers of DIAG and IOC.
[Procedure]
(1) Touch "0".
Display shows the version numbers of DIAG and IOC.
(2) By touching any position of the touch panel, display resumes DIAG MENU.
1. TP
[Function]
Test touch panel.
[Procedure]
(1) Touch "1" on the display panel.
A "+" will be shown on the upper left corner of the display.
(2) By touching "+", it moves to the next position.
In case of NG: Display indicates [tp ERROR 1].
By pushing Main display OFF/ON switch, the display resumes DIAG MENU.
(3) By touching "+" in order of upper left, upper right, lower left then lower right positions, display
resumes DIAG MENU.
2. Set Log File Number
[Function]
For setting log le number.
[Procedure]
Not used
3. Batch 1
[Function]
Executes clock, ROM, RAM and drawer tests automatically.
[Note]
Executing Batch 1 changes the settings to pre-dened date and time; therefore, the date and time
settings must be adjusted accordingly after performing Batch 1.
There are two types of drawer cables. The long cable is for drawer 1 and the short one is for
drawer 2.
[Procedure]
(1) Connect a drawer with the cable for drawer 1.
(2) Touch "3" on the screen.
(3) Clock, ROM, RAM,and drawer tests are executed automatically then display resumes DIAG MENU.
