V-R7000/V-R7100
– 41 –
H. LCD ASSY
H-1. Remove the LCD ASSY.
H-2. The parts confi guration of the LCD ASSY is as follows.
PLATE/LCD/R
CABLE/LCD
CABLE/LCD/BL
PLATE/LCD/L
CUSHION/LCD/V
CUSHION/LCD/H
CUSHION/LCD/V
LCD ASSY
S3
Note on reassembling
• Be sure that no dust or dirt is on the touch panel and LCD surfaces.
