Casio XJ-A141 User Manual

46
POWER : Green steady A system problem has occurred, which may cause problems with some
functions. Turn off the projector, disconnect the power cord from the
projector and wait for all of the projector’s indicators to go out. Next,
reconnect the power cord and turn the projector back on.
If the error occurs again when you turn power back on, contact your
retailer or nearest authorized CASIO Service Center.
Press the [ESC] key to clear the warning message.
LIGHT : –
TEMP : –
Message : A system problem has
occurred. Normal
projection is not possible.
POWER : Green steady
LIGHT : –
TEMP : –
Message : There is some problem
with the system.
The audio function may
not operate correctly.
POWER : Green steady The USB connection was terminated because of a problem with the USB
port. To use the USB function, turn off the projector and then turn it back
on again.
If the error occurs again when you turn power back on, contact your
retailer or nearest authorized CASIO Service Center.
Press the [ESC] key to clear the warning message.
LIGHT : –
TEMP : –
Message : There is a problem with
the USB port.
POWER : Green steady Zoom and focus cannot be performed due to some trouble in the optical
drive circuit. Turn off the projector and then turn it back on again.
If the error occurs again when you turn power back on, contact your
retailer or nearest authorized CASIO Service Center.
Press the [ESC] key to clear the warning message.
LIGHT : –
TEMP : –
Message : Zoom and focus cannot
be performed for some
reason. Try turning the
projector off and then
back on again.
If this message reappears,
request servicing.
POWER : Amber flashing J
Red steady
The projector was turned off automatically due to some problem that was
probably caused by external digital noise or some other reason. Confirm
that the POWER/STANDBY indicator is lit red (without flashing). After
checking the POWER/STANDBY indicator, disconnect the power cord
from the projector and wait for all of the projector’s indicators to go out.
Next, reconnect the power cord and turn projector power back on.
If the error occurs again when you turn power back on, contact your
retailer or nearest authorized CASIO Service Center.
LIGHT : –
TEMP : Red steady
Message : –
POWER : Amber flashing J
Red steady
The projector was turned off automatically because the light source unit
turned off or did not turn on. After confirming that the POWER/STANDBY
indicator is lit red (without flashing), unplug the power cord. Wait for a
short while and then plug it back in and turn on the projector again.
If the error occurs again when you turn power back on, contact your
retailer or nearest authorized CASIO Service Center.
LIGHT : Red flashing
(0.5-second interval)
TEMP : Red flashing
(0.5-second interval)
Message : –
Indicator/Error Message Description and Required Action

Casio XJ-A141 Specifications

General

Matrix size	0.55 \
Number of colors	16.78 million colors
Native aspect ratio	4:3
Projection distance	- m
Projection technology	DLP
Contrast ratio (typical)	2000:1
Screen size compatibility	15 - 300 \
Projector native resolution	XGA (1024x768)
Keystone correction, vertical	-30 - 30 °
Offset	100 %
Throw ratio	1.4 - 2.8:1
Optical zoom	2 x
Focal length range	- mm
Service life of light source	20000 h
Full HD	No
HD-Ready	Yes
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC, PAL 60, PAL M, PAL N, SECAM
Supported graphics resolutions	1024 x 768 (XGA)
RMS rated power	1 W
Number of built-in speakers	1
USB connector type	USB Type-A
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	0
Noise level	35 dB
Noise level (economic mode)	29 dB
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DEU, ENG, ESP, FRE, ITA, JPN, KOR, SWE
Placement	Desktop, Ceiling
Product type	Standard throw projector
Product color	White
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.4 W
Power consumption (typical)	210 W
Power consumption (PowerSave)	110 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Cables included	AC, Composite, VGA

Weight and Dimensions

Depth	210 mm
Width	297 mm
Height	43 mm
Weight	2300 g
