A. LSA MODULE (LASER SOURCE)
NOTE: The connector lock is very fragile. Be careful when removing the FPC cable.
Stub
Lens
XJ-A240/A245
A-3. Loosen two screws (S2).
A-4. Unscrew the screw
(S4). A-5. Release the latch and remove the FPC cable.
• If there is visible damage to the plug or if the plug is difficult to install, use
Screws (S4)
NOTE: The LSA module is sensitive to static electricity. It needs to be handled with care. A-1. Remove the plug. <ASSEMBLY
NOTE: LSA
MODULE>
Screws (S2)
LSA MODULE
LSA COVER
new plug, reuse of the old plug is not allowed. A-2. Loosen the screws (S2), then
remove the LSA cover.
Screws (S2)
Screws (S2)
Handles
Screws (S2)
A-6. Hold the LSA module by the handles and remove it.
NOTE: Do not strip the FPC cable cover. NOTE: Do not
touch the lens and FPC cable outlet.
-15-
