Page 4 of 14 EQ2009 R 1.6 1.8 Rev. 02 del 2/05/2011
3) CONTROLS POWER
P1
It set the power of the motor 1.
P2
It set the sensibility to the
obstacle while motor 1 is working.
P3
It set the sensibility to the obstacle
during slowing down of the 2 motors.
P4
It set the power of the motor 2.
P5
It set the sensibility to the
obstacle while motor 2 is working.
P6
It set the speed of slowing down of the 2
motors.
Top set P2, P3, P5, P6 (cap.10)
4) DIP-SWITCH S1 FUNCTIONS
DIP 1
ON
Automatic closing at the end of the work time-break after an opening controlled by the input of START.
OFF
Automatic closing after the work time-break excluded.
DIP 2
ON
Automatic closing at the end of the pedestrian time-break after an opening controlled by the input of
PEDESTRIAN
OFF
Automatic closing after the pedestrian time-break excluded.
DIP 3
ON
Active command inputs as START and PEDESTRIAN.
OFF
Active command inputs as OPEN and CLOSE separate
DIP 4
ON
Input radioreceiver RX1 it works as terminal block START.
OFF
Input radioreceiver RX1 it works as step-by-step.
DIP 5
ON
Same time of work for both the motors on M1.
Working with 1 motor only, dip 5 OFF
OFF
Time of work separate and independent for both the motors.
DIP 6
ON
The motor /s still works for 3 second after the activation of the limitswitch CLOSES
OFF
The motor/s only works till the activation of the limitswitch CLOSES
DIP 7
ON
Automatic closing at the end of the work time-break after an opening controlled by the input radioreceiver RX1.
OFF
Automatic closing after the work time-break excluded.
DIP 8
ON
SAFETY EDGE 2 during the opening, it stops the movement and it closes totally.
OFF
SAFETY EDGE 2 during the opening, it stops the movement and it closes only for 2 seconds.
DIP 9
ON
High threshold of starting encoder
OFF
Low threshold of starting encoder
DIP 10
ON
Short closing impulse on.
OFF
Short closing impulse off.
4.1) DIP-SWITCH S2 FUNCTIONS
DIP 1
ON
Dead man working
OFF
IMPULSIVE working.
DIP 2
ON
Semiautomatic program. In opening it doesn't accept START impulses. It is possible to use it for the function
clock.
OFF
Program step-by-step: OPEN-STOP-CLOSE-OPEN
DIP 3
ON
Maximum power to the motors in closing in the last 2” on.
OFF
Maximum power to the motors in closing in the last 2" off.
DIP 4
ON
Power starting motors on.
OFF
Power starting motors of.
DIP 5
ON
In opening and time-break an impulse of Photocell 1 close again after 2."
PHOTO 1
Motors
without encoder
only
OFF
Standard work on photocell 1
when the gate is closed and foto 1 obscurated ,the gate not open.
during the closing and foto 1 obscurated ,the gate stop and reopen when the foto1 is
liberated (in this operation is activated also the electrolock).
during the opening and foto1 obscurated ,the gate stop and reopen when the foto1 is
liberated (in this operation is activated also the electrolock).
DIP 6
ON
When the gate is closed, the START opens if PHOTOCELL 2 are obstructed.
OFF
When the gate is closed, the START doesn’t open if PHOTOCELL 2 are obstructed.
DIP 7
ON
Pre-alarm signal clinking 1 sec.
OFF
Pre-alarm signal clinking 4 sec.
DIP 8
ON
Output signal clinking intermittent.
(during the closing: slow clinking, During time-break : fixed light. During the opening fast clinking)
OFF
Output signal clinking fixed.
DIP 9
ON
Working with 2 motors (type double leaf).
OFF
Working with 1 motor on M1 (type sliding gate or 1 leaf).
DIP 10
ON
Admittance to the planning menu.
OFF
Disposition of the control panel in work condition.
