2) ELECTRIC CONNECTIONS
PLUG
DESCRIPTION
M1
1-2
Net feeding 230V (obligatorily respect the connections: neutral to the clamp 1, phase to the clamp 2).
M2
TERRA G
3 fixed clamps with the symbol of grounf for line and motors.
M3
3-4
Output signal clinking 230V.
M4
5-6-7
Output motor 1 (delayed in closing ). Pedestrian leaf. Opening to the clamp 5, common to the clamp 6, closing
to the clamp 7.
M5
8-9-10
Output motor 2 (delayed in closing ).. Opening to the clamp 8, common to the clamp 9, closing to the clamp
10.
M6
11-12
Light of courtesy, clean contact N.O. max.230V 4 Amp (see S3, dip 8).
M7
13-14
Output 12Vdc, max. 200 mA.
Electric
connections for
motors
without encoder
14-15
Input N.C. SAFETY EDGE 1.
 In opening it arrests the movement, in closing it reverses the sense of march for 2"
with operation type A (S3, dip 3 OFF).
 It always reverses the sense of march for 2" in the operation type B (S3, dip 3 ON).
14-16
Input N.C. SAFETY EDGE 2.
 In opening it reverses the sense of march for 2", in closing it arrests the movement
with operation type A (S3, dip 3 OFF).
 Input N.O. of REARMAMENT.
It becomes the input of rearmament of the control panel after the intervention of
Safety edge 1 in the operation type B (S3, dip 3 ON).
M8
17-18
Input N.C. PHOTOCELL 1.
Photocell trained in both the senses of march.
The conditions of operation depends on S2 – dip 5.
17-19
Input N.C. PHOTOCELL 2. Photocell activates only in closing (it arrests and it reopens).
The conditions of operation with the gate is closed depends on S2 - dip 6.
M7
13
Power encoder positive brown
Electric
connections for
motors
with encoder
14
Power encoder negative blue
15
Input sensor signal(black) of the shaft 1 encoder
16
Input sensor signal(black) of the shaft 2 encoder
M8
17-18
Input N.C. PHOTO 1 the operation modality depends from S3-dip 9
17-19
Input N.C. PHOTO 2 the operation modality depends from S3-dip 10
M9
20-22
Input N.C. LIMIT SWITCH OPENING 1.
Limit switch of opening of the motor 1.
If the motor is complete with limitswitches, you have to
connect them to the controlboard but not to the motor
phases. Exceptionally it is possible to connect the limit
switches on the motor phases, to connect: put Dip 2 of S4
in ON and made short-circuits on 20,21,22,23,24 of M9.
Warning: with test-triac OFF(Dip 2 of S4 in ON),use all
security (photocells, safety edges) as is possible.
21-22
Input N.C. LIMIT SWITCH CLOSING 1.
Limit switch of closing of the motor 1.
22-23
Input N.C. LIMIT SWITCH OPENING 2.
Limit switch of opening of the motor 2.
22-24
Input N.C. LIMIT SWITCH CLOSING 2.
Limit switch of closing of the motor 2.
M10
25-28
Input N.C. STOP.
It arrests the movement of the gate.
26-28
Input N.O. START (S1 - dip 3 ON).
Input N.O. OPEN (S1 - dip 3 OFF).
27-28
Input N.O. PEDESTRIAN (S1 - dip 3 ON).
Input N.O. CLOSING (S1 - dip 3 OFF).
M13
29-30
Output warning light functions 24Vac.
It is out to when gate is closed , it has turned on when gate is open.
30-31
Output ELECTROLOCK; 12Vac, max. 1A.
M11
32-33
Output 24Vac to use for feeding the transmitting station of the photocells when the function "test photocells" is
activated (S3 dip 1-2 ON)
33-34
Output 24Vac.
42-33
Input N.O. EMERGENCY OPERATING
M12
35-36
Input aerial for radioreceiver RX
Aerial Cable to 36, eartn to 35.
41
Input external N.A. of RX1, GND 35
M14
37-38
Contact N.C. safety.
The opening of the contact removes the feeding from the spools of the relays disarming the outputs.
M15
39-40
Clean contact of the 2° channel of the radioreceiver on the connection J1 RX.
WARNING : The inputs N.C. not used they must obligatorily be short-circuits toward the commune of the entries
