Cassida C200 coin counter/sorter/wrapper
Moving money forward
14
3. Attach the coin tubes to the C200 by gently sliding each tube into the proper
slot in the base of the machine as shown in Figures 2 and 3.
Figure 2 - Installing coin tube
Figure 3 - Coin tube in proper position
Figure 4 - US model Figure 5 - Canadian model
Coin tube locations for each country varies. Use coin denomination labels to
help you place the coin tubes. Coin tubes should be placed exactly underneath
the coin denomination label.
8
7
4
3
2
1
5
6
8
1
7
4
3
5
6
2
(Set up for other countries may vary)
15
4. Set coin roll batch quantities (see section 2.4) for each coin denomination by
pressing and holding the “+” button for approximately three seconds until “L” is
shown in the display. This programs each coin denomination for standard bank
coin roll sizes.
US Model Canadian Model Other Countries
$2 25 Varies
$1 25
25¢ 40
10¢ 50
5¢ 40
1¢ 50
5. Load coins into the coin hopper and press the “START/STOP” button. The C200
will automatically dispense the correct number of coins into each coin tube.
6. When the number of dispensed coins equals the batch quantity for any
denomination, the C200 will stop and display a message on the control panel. For
example,aftertherstbatchof50pennieshasbeencounted,thefrontpanelwill
display:
1c
or
50 (quantity reporting)
1
c 0.50 (value reporting)
NOTE: When operating in batch mode, the C200 will keep a running total for
each denomination coin. For example, after four batches of 50 pennies have
been dispensed, the C200 will stop and display:
1
c
or
200 (quantity reporting)
1
c 2.00 (value reporting)
7. Remove the full coin tube from the C200 and slide out the paper wrapper
containing the coins. Crimp the open end of the wrapper. Insert and empty
wrapper in the coin tube and reinstall the coin tube.
8. Press the “START/STOP” button to continue batching.
