4.Unpacking & Assembly
Warning:Due to the weight of the stove it is recommended that two people
perform the unpacking and
assembly
Unpacking
Before assembling,place check contents against the following list and advise your
dealer immediately if any parts are missing.
1 x Stove body
1 x Flue Connector c/w Fireproof Gasket
1 x Firebox Top Baffle Plate A
1 x Firebox Top Baffle Plate B
1 x Flue Blanking Plate
1 x Ash pan & Handle
1 x Grate
1 x Fixings Kit
1 x Heat Resistant Glove
1 x Vermiculite plate set
Assembly
Unpack the stove and remove packing materials.Open the door and remove ashpan,
flue adaptor and fixing fit from inside the stove.
1.
Sit the stove upright and attach the flue adaptor as showed picture below, using
the screws supplied. Ensure the fireproof gasket is correctly seated in the
base of the flue adaptor.
2.
Install the blanking plate in the rear of the stove when the normal flue
exit is
required.
