If the rear
mounting flue configuration is to be used, the blanking plate will be
fitted to the top of the stove and the flue connector to the rear panel.
3.
Set ashpan in position . An ashpan handle is supplied for when the stove is in
use.
5.Installation of the stove
PLEASE READ THESE INSTRUCTIONS CAREFULLY
For your safety it is very important that your stove is correctly installed. Our Stoves cannot
accept any responsibility for any fault arising through incorrect installation or use.
Material Clearances
The stove must have a minimum clearance to a combustible below.
Fig 4
It is recommended that the stove be installed at least 400 mm from combustible
materials. However, any household furnishings should be at least 1000mm away as
they could be adversely affected by heat.
If the stove is to be installed in a non combustible recess it is recommended that
150mm clearance is left at the back and sides for maintenance and to allow air to
circulate around the stove
Due to the heat of a hot stove, a suitable fire guard should be used to provide
additional protection. Never allow young children to be left unsupervised in a room
containing a hot stove.
