The unit should be placed on a stable, smooth surface. Do not apply
force onto the controls protruding from the hob.
1. Cut out worktop to the supplied
dimensions shown, with suitable
equipment. Seal the cut edge
of the worktop using silicone or
PTFE and allow to dry before
fitting the Hob.
2. Stretch out the supplied seal
along the underside edge of
the hob, ensuring that the ends
overlap. Do not use adhesive to
fix the hob into the worktop
3. Once the seal is fitted, position the hob into the cutout in the
worktop. Apply gentle downwards pressure onto the hob to push it
into the worktop, ensuring a good seal around the outer edge.
• Make sure the Induction Hob is well ventilated at all times and that
the air inlet and outlet are not blocked. Ensure the appliance is
always in good working state.
CAUTION!
The safety distance between the hotplate and the cupboard
above the hotplate should be at least 760 mm.
