6
A (mm) B (mm) C (mm) D (mm) E
760 min. 50 min. 20 min.
Air intake
5 min.
Air exit 5min.
AFTER YOU HAVE INSTALLED THE HOB
• Make sure that the power supply cable is not accessible through
cupboard doors or drawers.
• Check that there is adequate flow of fresh air from outside the
cabinetry to the base of the hob.
• Make sure that a thermal protection barrier is installed below the base
of the hob, if the hob is installed above a drawer or cupboard space.
• Check that the isolating switch is easily accessible by the customer.
