CaterSense -01 User Manual

CaterSense the Intelligent answer
CS-INST1-0.01
Model: CaterSense 01 Page 8 07-11
2.02 Mode Set-up
Once the above has been carried out, the system is now ready to be powered up.
Ensure the fans are running at the speed at which they draw least current. THIS IS NOT
NECESSARILY THE LOWEST SPEED. IMPORTANT – allow system to run and settle.
If the fan is monitored via an external source, and the "fan healthy" signal is provided from a
volt-free contact, ensure that the contact is closed.
The system will produce a short beep. Change the speed of the fans to the speed at which
they draw maximum current. THIS IS NOT NECESSARILY THE HIGHEST SPEED.
IMPORTANT – allow system to run and settle.
If the fan is monitored via an external source, and the "fan healthy" signal is provided from a
volt-free contact, ensure that the contact is closed.
The set-up is now complete and the system is ready to run.
1) PRESS SYSTEM CONDITION
GAS VALVE
FAN
All other LEDs
2) PRESS SYSTEM CONDITION
GAS VALVE
FAN
All other LEDs
3) PRESS GAS VALVE
All other LEDs
