5.6 Changing the Transmitter Identity Codes
Changing the ID Code requires use of a Cattron RAC16A Series Programmer. Refer to Figure 2 for the handheld
transmitters.
1. Confirm that the batteries are fresh and the transmitter is off (refer to Troubleshooting).
2. Remove the screws on the back of the transmitter and remove the back panel from the case. On ‘A’
Series IP67 rated transmitters, remove the battery door and batteries before removing the back of the
transmitter.
3. Using the RAC16A Series Programmer, attach the programming plug to the 4-pin connector on the circuit
board. Verify that the ID Code is displayed.
4. Enter the new ID Code and press the PRG key.
5. Reassemble the transmitter in reverse order, making sure that the battery wires do not get pinched
between the back panel and the case. Tighten the screws snugly. On ‘A’ Series IP67 rated transmitters,
replace the battery door and batteries after replacing the back panel. ‘A’ Series captive screws should be
tightened until snug, plus half a turn.
Refer to the RAC16A Series User’s Manual for more detailed instructions.
5.7 Transmitter Specifications
