CT24 MCU
User Manual
32
9M02-7608-A001-EN
Version 2.0
Table 6: Terminal Blocks – Spring Clamp
TYPE
ALL EXCEPT
ANALOG
ANALOG
WIRE RANGE
AWG
Spring
clamp
ASP046 series
ASP044
series
0.08 mm
2
to 1.5 mm
2
28 to 16
Table 7: Terminal Blocks – Screw Type
TYPE
ALL EXCEPT
ANALOG
ANALOG
WIRE RANGE
AWG
Screw
249 series
n/a
0.08 mm
2
to 2.5 mm
2
28 to 12
Screw
n/a
369 series
0.08 mm
2
to 1.5 mm
2
28 to 16
