Cayin CS-100CD - Specifications; CD Player Specifications; Digital Input Specifications; Digital Output Specifications

2
Ⅲ SPECIFICATIONS
1. CD PLAYER:
Support CD，CD-R，16-bit 44.1kHz
2. Digital Input
Optical input: 16/24-bit 44.1-192kHz
Coaxial input: 0.5V @75Ω，16/24-bit 44.1-192kHz
USB Audio :
Compatible with Audio Class 1.0 and Audio Class 2.0.
Support Windows 7® Windows 8® Windows 8.1® Windows 10® and Mac OS(10.6.3 and
above)
2. Digital Output
Optical output: 16/24-bit 44.1-192kHz. According to the IEC958 standard.
Coaxial output: 0.5V @75Ω，16/24-bit 44.1-192kHz，According to the IEC958 standard.
AES/EBU output: 110Ω，16/24-bit 44.1-192kHz，According to the IEC958 standard.
 Output level: 2.3V±2dB
 Frequency response: 20Hz～20kHz±0.5 dB
 Distortion and noise: ≤-60dB
 S/N ratio: >100dB
 Dynamic range: >110dB
 Channel separation(1kHz): <-80dB
 Power requirements: ～230V±5% 50Hz
 Weight: ≈12kg
 Dimension: ≈420mm×372mm×117mm
 Power consumption: 45W
Ⅳ FRONT PANEL
