ZC-F11 - 10 -
PRODUCT SPECIFICATIONS
GB
ZC-F11C4 ZC-F11CH4 ZC-F11C3 ZC-F11CH3
Video signal system CCIR
Video output 1.0 Vp-p/75 Ω
Scanning system 2:1 interlace
Min.Resolution (horizontal TV line) 380 560 380 560
Minimum object illumination F1.2 0.09Lux 0.18Lux 0.09Lux 0.18Lux
Minimum object illumination F0.8 0.04Lux 0.08Lux 0.04Lux 0.08Lux
S/N ratio 50 dB or more
Gamma characteristics 0.45
Photo-image sensor 1/3-inch CCD
Effective pixel count (Horizontal) 500 752 500 752
(Vertical) 582 582 582 582
Scanning frequency (INT. sync mode) Horizontal 15.625 KHz / Vertical: 50.00 Hz
Sync modes Line Lock/Internal
Iris control DC: DC iris
AES (sec): Linear shutter (1/50 to 1/100000)
VIDEO: Vcc= DC 12 V, 50 mA max. Sig.= 0.7 Vp-p High impedance
Power AC 24 V ± 10% or AC 230 V ±10%
(50 Hz ± 1%) (50 Hz ± 1%)
DC 12 V ± 10%
Maximum power consumption 5 W or less 7 W or less
Lens mount CS mount (C mount with optional 5mm adapter)
Operating environment -10°C to +50°C/14°F to 122°F, 85% RH or less (no
condensation)
Storage environment -20°C to +60°C/-4°F to 140°F, 95% RH or less (no
condensation)
External dimensions 60 (W) x 54 (H) x 103.3 (D) mm
Weight 300g 600g
Input/output terminals Video output: BNC
Auto-iris output: 4-pin connector (D4-151N-100/equivalent)
Power input: 2-pin screwless terminal 2-core 2.0m cord
blocks
Switches Iris control: DC/AES/VIDEO
BLC: BLC/OFF
Sync mode: INT./L.L.
Adjustments Line Lock Phase adjustment
DC iris level adjustment (adjustable POT in only DC iris
mode)
The CE Marking is a Directive Conformity mark of the European Union (EU).
* The specifications and appearance of the product may change without notice.
