ZC-F11 - 19 -
1 Flange back adjustment wheel
If focus needs to be adjusted after the lens has been mounted, loosen the Flange back lock screw
(7) and rotate the Adjustment wheel to adjust.
2 DC iris level adjust POT
Adjust DC iris level manually.
3 BLC (Back Light Compensation) mode switch
When strong light (sun, sky, illumination, etc.) is present behind the object
being photographed, the object will appear dark. In this case, put this
switch in the
BLC
position.
4 Sync mode switch
For setting the sync mode.
L.L.: Line Lock mode
INT.: Internal sync mode
5 Line phase adjustment POT
This POT is used to adjust phase when the Sync mode switch is set to
L.L.
position.
(Default position: Most left hand side adjustable 0˚~180˚)
6 Auto-iris output connector
For connecting the cable of an auto-iris lens. The pin assignment is following.
No. DC VIDEO
1 CONTROL – DC 12 V (max. 50 mA)
2 CONTROL + N. C.
3 DRIVE + VIDEO
4 DRIVE – GND
7 Flange back lock screw
8 Auto-Iris mode switch
For switching the output from the auto-iris connector (6). Shutter speed is fixed at 1/50 sec. when
switch is set to
DC
or
VIDEO
position.
DC: To be set when using a non-amp auto-iris lens.
AES: To be set when using AES (Auto Electronic Shutter).
VIDEO: To be set when using an auto-iris lens a built-in amp.
9 Video output connector
Connected to the TV monitor with a coaxial cable.
0 Power input terminal. Use a DC 12V (10.8 to 13.2 V) or AC 24 V (21.6 to 26.4 V, 49.5 to 50.5 Hz)
power supply. (ZC-F11C4/ZC-F11CH4)
Caution: Use only with a 24V AC power supply marked class 2 or +12VDC power supply
AC Power cord: Use AC 230V, 50Hz (ZC-F11C3/ZC-F11CH3)
Caution: Use only with a 230V AC
DESCRIPTION OF FUNCTIONSGB
