CBE CB510 - Page 7

L=3mt
1
GB
ENGLISH
GB
7
CONNECTIONS
1
1)
2)
-12V supply(BLACK)
+12V supply(BLEU)
12V CONNECTION
2
1)
2)
Output+12Vd.c.(S)powersupplysignal(ToconnecttoCBEequipment)
/
SIGNAL
3
Temperaturesensor(mod. “CTCB”) ,whereit
cannotbeaffectedbyotherheatsources
Whenconnected,thechargingvoltageisadaptedaccordingtothetemperature
measuredbythesensor.
tobeplacedclosetothebattery
CONNECTIONBATTERY TEMPERATURESENSOR(optional)
-Technicaldataareindicatedalsoonthelabelinsidethecover-
Chargingline
selector
15A
25A
F1
CB510
CB516
B
C
A
Connectionbattery
temperaturesensor
“CTCB”
3
230V On/Off
Fuse230V
F2-T3.15A
1
2
BLACK
2
BLACK
BLACK
N B : F A C T O R Y S E T T I N G O F T H E C H A R G I N G L I N E S E L E C T O R I S O N " A ”
Temperaturesensor
mod."CTCB"
(optional)
tobeplacedclosetothebattery
