CBE CB510 - Installation

Fig.1-DIMENSIONS(mm): Fig.2- VERTICALINSTALLATION
INSTALLATION
GB
ENGLISH
GB
9
180
140
85
110
110
197
157
IMPORTANT: -Theinstallationofthisdevicemustbecarriedoutbyspecialisttechnicians.
-Caution,donotconnectthebatterycharger
whenageneratorsetwithnonstabilisedoutputvoltageisemployed
withpowermainsvoltageexceedingtheratedvalue(230V ±10%)
-Donotcarryoutanymaintenancewhenthebatterychargerisconnectedtothe
230V powersupplynet.
- Incaseofbatterychargermisuse,theguaranteebecomesinvalidandthe
manufacturerdeclinesallresponsibilityfordamagestopeopleandproperty.
-Thisappliancecanbeusedbychildrenaged8yearsormoreandpeoplewith
reducedphysical,sensoryormentalcapabilitiesorlackofexperienceor
knowledge,onlyprovidedtheyarebeingsupervisedortheyhavebeeninstructed
concerningtheuseoftheapplianceinasafewayandthattheyunderstandthe
hazardsinvolved.Childrenshallnotplaywiththeappliance.
BATTERY CHARGER
CABLES
BATTERY
Warning:
1
1
-Installthebatterychargerinanappropriatehousing,dryandventilated;maximumefficiencycanbe
obtainedwhenthebatterychargerisinstalledinaverticalposition(seefigure2),keepingthefrontata
minimumdistanceof300mmandthebottomandtopataminimumdistanceof100mmfromthehousing
sides.
- Donotcoverairintakes.
- Toguaranteeproperairexchange,installationoftwoairintakes(oneplacedonthetopandoneonthe
bottom,seefigure2)ensureaworkingtemperatureinsidethehousingnotexceeding50°C.
- Makesurethatthe230V safetyswitchcanbeeasilyreached.
- Theconnectiontopowersupplymainsshallbemadeinaccordancewithnationalinstallationrules.
- Beforedisconnectingthebatterychargerfrom230V powersupply,turnthesafetyswitchoff.
- Installationrequiresthefixingof4pinsthatcanbeeasilyplacedonthe4sides.
- ThebatterychargercanbeinstalledtogetherwithCBE12Vand230Vdistributionpanels,usingthe
appropriatemodularjoints.
- Mains connection: use a 3x1.5mm² cable, type H05 RN-F or equivalent.
- Battery connection: use N07 V-K cables having adequate cross section (minimum cross section 4mm²).
- Fix the cables with the relevant cable fastenings devices supplied.
- Protect cables from any possible damage.
- Lead-acidbatteriesshallbepositionedinawellventilatedplace.
- Useonly12V rechargeableleadbatteries(capacity>40Ah).
- Donotusewith “notrechargeable"batteries.
- Exhaustedbatteriesshallbedisposedinaccordancewithexistingenvironmentalprotection
regulations.
(6cells)
